APPENDIX I PAGE 1/1
MOLEX - WALDOM NYLON CONNECTOR SYSTEM USED BY THE MOTION GROUP
The connectors used on Motion Group equipment are nylon connectors are manufactured by Molex and are refered to as .062 style (pin diameter)
or .093 (large driver motors only). They are available from Newark, Allied, and Digi-Key and come in 1 to 36 positions with locking and mounting
tabs which snap-in to punched holes on brackets or enclosures.
TYPICAL $ POLES TYPE PART # NEWARK # USED ON
5.84/10 4 (.062) MALE HOOD 03-06-2041 31F1004 HOME SENSOR ASSEMBLY
5.95/10 4 (.062) FEMALE RECT 03-06-1041 31F1005 HOME SENSOR CABLE
1.86/5 6 (.062) MALE HOOD 03-06-2062 31F1008 STEP MOTOR ASSY
2.07/5 6 (.062) FEMALE RECT 03-06-1061 31F1009 MOTOR OUTPUT
1.86/5 6 (.093) MALE HOOD 03-06-2062 31F1008 STEP MOTOR ASSY
2.07/5 6 (.093) FEMALE RECT 03-06-1061 31F1009 MOTOR OUTPUT
(Strain Relief Hoods are available on request)
Contacts for Connector Sets .062 SIZE
6.79 FEMALE SOCKETS LARGE TAB 02-06-1103 31F1027 22-18 GUAGE WIRE
MALE PINS LARGE TAB 02-06-2103 31F1026 22-18 GUAGE WIRE
FEMALE SOCKETS SMALL TAB 02-06-1132 31F1029 30-22 GUAGE WIRE
MALE PINS SMALL TAB 02-06-2132 31F1028 30-22 GUAGE WIRE
Contacts for Connector Sets .093 SIZE
6.79 FEMALE SOCKETS LARGE TAB 02-06-1103 31F1027 22-18 GUAGE WIRE
MALE PINS LARGE TAB 02-06-2103 31F1026 22-18 GUAGE WIRE
FEMALE SOCKETS SMALL TAB 02-06-1132 31F1029 30-22 GUAGE WIRE
MALE PINS SMALL TAB 02-06-2132 31F1028 30-22 GUAGE WIRE
In general, single wires use small tab contact; double wires the large tab
Tooling
105 RATCHET TOOL .062 DIA HTR-2262 11-01-006 30F338 MAKES PERFECT CRIMPS
105 RATCHET TOOL .093 DIA HTR-XXXX 11-01-006 30F338 MAKES PERFECT CRIMPS
13 HAND TOOL HT-1921 11-01-0015 31F1049 REQUIRES PRACTICE
12 EXTRACTOR .062 DIA HT-2285 11-03-0002 30F773 SPRING LOADED PUNCH-OUT
12 EXTRACTOR .093 DIA
Nylon Connector Designer/Service Kit
Contains male/female housing assortment, hand crimper, pin extractor (not as easy to use as spring extractor; see above),
contacts, and case.
40 DESIGNER KIT .062 WM-072 30F774
40 DESIGNER KIT .093
All of the above, including custom cable sets are available from the factory.
Note: When disconnecting, grasp the mounting tabs, (not the wires) and rock from top to bottom (unseat the locking bump) rather than SMCe to
SMCe and then pull the connection apart. The connections unseat easily with the right technique.
Contact factory for Heavy Duty Connectors with Metal Shells, Retainers, and Strain-Reliefs.
