340
Technical data
Engine
̄ Engine
Model C 240 (203.261) 1
C 240 4MATIC (203.281) 1
1 The quoted data apply only to the standard vehicle. See an authorized Mercedes-Benz Center for the corresponding data of all special bodies and special equipment.
C 320 (203.264) 1
C 320 4MATIC (203.284) 1
Engine 112 112
Mode of operation 4-stroke engine, gasoline injection 4-stroke engine, gasoline injection
No. of cylinders 6 6
Bore 3.54 in (89.90 mm) 3.54 in (89.90 mm)
Stroke 2.68 in (68.20 mm) 3.31 in (84.00 mm)
Total piston displacement 158.5 cu in (2597 cm 3 ) 195.2 cu in (3 199 cm 3 )
Compression ratio 10.5:1 10:1
Output acc. to SAE J 1349 168 hp/5500 rpm
(125 kW/5 500 rpm) 215 hp/5700 rpm
(160 kW/5700 rpm)
Maximum torque acc. to SAE J 1349 177 lb-ft/4 500 rpm
(240 Nm/4500 rpm) 229 lb-ft/3000 - 4600 rpm
(310 Nm/3 000 - 4600 rpm)
Maximum engine speed 6200 rpm 6000 rpm
Firing order 1-4-3-6-2-5 1-4-3-6-2-5
Poly-V-belt 2380 mm 2380 mm
