Mercedes-Benz 2004 C-Class Wagon - Manual (Page 207)

207
Controls in detail
Loading
7 Hook
8 Eye
̈ Connect hook 7 to eye 8.
Tighten strap by pulling at the loose
end (arrow).
Unloading and folding
̈ Loosen the straps.
̈ Disconnect hook 7 from eye 8.
̈ Unload skis.
̈ Close flap in cargo compartment.
̈ Fold and flatten ski sack lengthwise.
̈ Place folded ski sack inside recess of
backrest.
̈ Fasten velcro strap.
̈ Close ski sack compartment cover.
Removing the ski sack
You can remove the ski sack for cleaning
or drying.
1 Button
2 Ski sack frame
3 Flap
̈ Open tailgate.
̈ Press button 1.
The flap 3 opens downward.
̈ Press button 1 firmly until ski sack
frame 2 is released.
̈ Pull ski sack frame 2 with ski sack
out.
