309
Practical hints
Opening/closing in an emergency
̄ Opening/closing in an emergency
Sliding/pop-up roof*
You can open or close the sliding/pop-up
roof manually should an electrical
malfunction occur.
The sliding/pop-up roof drive is located
behind the lens 1 of the interior overhead
light.
̈ Pry off lens 1 using a flat blade
screwdriver.
̈ Slide both locking tabs 2 in direction
of arrow.
̈ Lower rear of cover and remove.
̈ Remove cover.
̈ Obtain crank 3.
̈ Insert crank 3 through hole.
̈ Turn crank 3 clockwise to:
ț slide roof closed
ț raise roof at the rear
̈ Turn crank 3 counterclockwise to:
ț slide roof open
ț lower roof at the rear
The sliding/pop-up roof must be
resynchronized after being operated
manually (
୴ page 201).
i
Do not disconnect electrical
connectors.
