624WBPF Woodburning Fireplace
3656O” (927 mm) 1/2” (13 mm)
3056M”
(768 mm)
3756M”
(946 mm)
42”
(1067 mm)
456M”
(1162 mm)
36” (914 mm)
38” (965 mm)
23” (584 mm) 1/2”
(13 mm)
14(6 ”
(378 mm)
856O”
(216 mm)
12”
(305 mm)
24” (610 mm)
226M”
(578 mm)
9”
(229 mm)
12”
(305 mm)
539042
MPL dims
Figure 1
Gas Line Entrance
(Bottom of Fireplace)
FirePlace diMeNSioNS
