Monessen Hearth WOODBURNING PENINSULAR 624WBPF - Manual (Page 12)

12
624WBPF Woodburning Fireplace
53D9052
chiMNey iNStallatioN
FP 548b
SHR
5/11/99 djt
Angle of Chimney at Ceiling
Size of Chimney Vertical 30˚
11" CF 2-Wall
FS2A
1756O" x 1756O"
(445 x 445 mm)
FS6A
17(6 " x 296 "
(454 x 753 mm)
CHIMNEY HOLE SIZE
table 1
1856O”
(470 mm)
CL
17” Min.
(432 mm)
23”
(584 mm)
46”
(1168 mm)
38”
(965 mm)
3” Min.
(76 mm)
226 ”
(575 mm)
3/16”
(5 mm)
FP2352
MPL framing
Figure 10
FP2352
FP1890
chimney install
8/08
Figure 13
Outer Pipe
Flue
Support Straps
Fasten Securely
Firestop
Chimney Support
Snap Lock Chimney
Support Securely to
Lower pipes Before
Fastening Support
Straps
FP1890
17”
2256QE”
756M”
30°
76QE”
FP1894
firestop spacer
8/08
Figure 11
Firestop Spacer
&0
FIRESTOP
Figure 12
Firestop Spacer installation at attic level
Inlet Air Pipe
Ceiling Joist Flue Pipe
Firestop Spacer
Chimney Section
Header
Firestop Spacer installation at Floor levels
Floor
Joist
Inlet Air Pipe
Flue Pipe
Firestop Spacer
Chimney Section
Header
