MITSUBISHI ELECTRIC 2033C SERIES UPS
MITSUBISHI
ELECTRIC 2033C SERIES UPS
OWNERS / TECHNICAL MANUAL
Page Number:
1-15
TABLE 1.3 Detail of Specifications
Rated Output kVA 7.5 10 15 20 30 40 50
Rated Output kW 6 8 12 16 24 32 40
AC INPUT CHARACTERISTICS
Configuration 3 phase, 4 wire
Voltage 120/208 V +15% ~ -25%
Frequency 60 Hz +/- 5%
Reflected Current THD 4% typ. at 100% load; 7% typ. at 50% load
BATTERY
Type VRLA
Ride Through
(at 100% load)
8min. 5min. 11min. 7min. 5min.
Nominal Voltage 360 Vdc
Minimum Voltage 300 Vdc
Number of Cells 180
AC OUTPUT
Configuration 3 phase, 3 or 4 wire
Voltage 120/208 V
Voltage Stability +/- 1%
Frequency 60 Hz
Frequency Stability +/- 0.01% in free running mode
Power Factor 0.8 nominal
Power Factor range 0.8 ~ 1.0 lagging (within output kW rating)
Voltage THD 2% typical THD at 100% Linear Load
4% typical THD at 100% non-linear load
Transient Response +/- 3% typical at 100% load step
+/- 1% typical at loss/return of AC power
+/- 3% typical at load transfer to/from static bypass
Transient Recovery 16.7 ms
Voltage Unbalance 2% typical at 100% unbalanced load
Phase Displacement 1deg. typical at 100% load
Inverter Overload 150% for 1 minute
System Overload 150% for 1 minute, 1000% for 1 cycle (with bypass available)
Bypass Overload 150% for 1 minute, 1000% for 1 cycle
Crest Factor Capabilities 3:1
ENVIRONMENTAL
Cooling Forced Air
Operating Temperature 32ﾟF ~ 104ﾟF (0ﾟC ~ 40ﾟC).
Recommended 59ﾟF ~ 77ﾟF (15ﾟC ~ 25ﾟC)
Relative Humidity 5% ~ 95% Non Condensing
Altitude 0 ~ 5000 feet No De-rating
Location Temperature-controlled, indoor area free of conductive contaminants
