MITSUBISHI ELECTRIC 2033C SERIES UPS
MITSUBISHI
ELECTRIC
2033C SERIES UPS
OWNERS / TECHNICAL MANUAL
Page Number:
1-14
1.4 Specifications
The UPS name plate displays the rated kVA as well as nominal voltages and currents. The
name plate is located on the interior side of the UPS front door.
TABLE 1.1 Power Specifications
Rated output
Power
Input voltage
3 phase / 4 wire
Output voltage
3 phase / 3 or 4 wire
7.5kVA/6kW
10kVA/8kW
15kVA/12kW
20kVA/16kW
30kVA/24kW
40kVA/32kW
50kVA/40kW
208
208
208
208
208
208
208
208
208
208
208
208
208
208
TABLE 1.2 UPS Module Information
UPS
(kVA)
CABLE
ENTRY
WIDTH
(in/mm)
DEPTH
(in/mm)
HEIGHT
(in/mm)
WEIGHT
(lb./kg)
HEAT LOSS
@ 208V
(kBTU/h)
7.5
BOTTOM
17.7 / 450
31.5 / 800
43.3 / 1100
562 / 255* 3.2
10
BOTTOM
17.7 / 450
31.5 / 800
43.3 / 1100
562 / 255* 3.9
15
BOTTOM
17.7 / 450
31.5 / 800
43.3 / 1100
816 / 370* 5.1
20
BOTTOM
17.7 / 450
31.5 / 800
43.3 / 1100
816 / 370* 6.5
30
BOTTOM
23.6 / 600
31.5 / 800
59.0 / 1500
1235 / 560* 8.8
40
BOTTOM
27.6 / 700
31.5 / 800
59.0 / 1500
1082 / 490
11.9
50
BOTTOM
27.6 / 700
31.5 / 800
59.0 / 1500
1082 / 490
14.6
*：7.5-30kVA Including batteries
