AWARD ® BIOS Setup
3-25
Current System Temp., Current CPU Temperature, POWER/SYSTEM/CPU
fan, Vcore, VTT, 3.3 V/+ 5V/+12V/-12V/- 5V, VBAT(V), 5VSB(V)
These items display the current status of all monitored hardware devices/
components such as CPU voltages, temperatures and all fans’ speeds.
CPU Critical Temperature
This item is used to specify a thermal limit for CPU. If CPU temperature
reaches the specified limit, the system will issue a warning and allows you to
prevent the CPU overheat problem. Settings: Disabled, 80°C/176°F, 85°C/
185°F and 90°C/194°F.
PC Health Status
This section is to monitor the current hardware status including CPU
temperature, CPU Fan speed, Vcore etc. This is available only if there is
hardware monitoring mechanism onboard.
↑↓→←
:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
Current System Temp. 32°C/89°F
Current CPU Temperature 58°C/132°F
POWER fan 0RPM
SYSTEM fan 0RPM
CPU fan 4560RPM
Vcore 1.66V
VTT 1.47V
3.3 V 3.33V
+ 5V 5.02V
+12V 12.05V
-12V -11.56V
- 5V -4.99V
VBAT(V) 3.22V
5VSB(V) 4.87V
CPU Critical Temperature [Disabled]
CMOS Setup Utility - Copyright(C) 1984-2001 Award Software
PC Health Status
Item Help
Menu Level
8
