Getting Started
1-5
Quick Components Guide
Component Function Reference
JWR1/JPW1 ATX power connectors See p. 2-7
JKBMS1 Mouse/keyboard connector See p. 2-8
USB Connectors Connecting to USB devices See p. 2-9
COM A & COM B Serial port connector See p. 2-10
L P T 1 Parallel port connector See p. 2-11
FDD1 Floppy disk drive connector See p. 2-12
IDE1~ IDE2 Hard disk connectors See p. 2-13
JCD1/JAUX1/JMD1 CD/AUX/Modem-in connectors See p. 2-14
CPUFA/SYSFA Fan power connectors See p. 2-15
JMDM1 Wake on ring connector See p. 2-16
JIR2 IrDA infrared module connector See p. 2-16
JFP1/JFP2 Front panel connectors See p. 2-17
JP20 Front panel audio connector See p. 2-18
JUSB1/JUSB3 USB front connector See p. 2-19
JBAT1 Clear CMOS jumper See p. 2-20
AGP Slot Connecting to AGP cards See p. 2-21
PCI Slots Connecting to expansion cards See p. 2-21
CNR Slot Connecting to expansion cards See p. 2-21
