Special Setups: A/V Equipment
VCR: Connect the cables to the TV as directed
on page 17, with one exception. Connect the
audio output connection to the appropriate input
on the back of the A/V receiver (as shown in
Table 1).
DVD: Connect the cables as directed on page
19 (using the COMPONENT-1 input), with one
exception. Connect the digital audio output
connection on the DVD player to the
appropriate digital input on the back of the
digital A/V receiver (as shown in Table 1).
DTV: Connect the cables as directed on pages
20-21, with one exception. Connect the digital
audio output connection on the DTV receiver to
the appropriate digital input on the back of the
digital A/V receiver (as shown in Table 1).
A/V Receiver: Connect as directed on page
18, with two additions. Use an S-Video cable
in step 1 if you have an S-Video VCR. The
TV outputs should be connected to the A/V
receivers input marked TV.
•Auto Standby: ON (See your A/V receiver’s
Owner’s Guide for this procedure). For all TV
use, the sound will come from the A/V receiver.
Not available with all A/V receivers.
•Digital Input Assignment for DVD: Assign
the digital input you used for your DVD player
to the A/V receiver’s DVD input selector. This
procedure is explained in your A/V receiver’s
Owner’s Guide.
•Digital Assignment for DTV: Assign the
digital input you used for DTV to the A/V
receiver’s DTV input selector. This procedure is
explained in your A/V receiver’s Owner’s Guide.
Infrared Emitter: Connect as shown on page
22.
Special Setups: TV
To correctly setup System 4 use the following
settings
•TV Speakers: OFF
•Audio Output: Fixed
See Audio Video Menu, page 31.
•TV Inputs Appropriately Named
See Input Assignment Menu, page 31.
Remote Control, pages 26-27.
•Set the slide switch to the TV position and
follow the programming instructions using the
A/V receiver code appropriate for your A/V
receiver, page 27 (Figure 5).
(For System 4 Home Theater IR Control)
Mitubishi M-VR1000/MR800 TV VCR 2 VCR 1 DVD
Mitsubishi M-RVR900/M-VR700 TV CABLE/DBS VCR DVD
Denon AVR2800 TV/DBS VCR 2 VCR 1 DVD/LD
JVC RX-888V TV VIDEO 2 VCR 1 DVD
Kenwood VR-2080 AV AUX LD VIDEO 1 DVD
Onkyo TX-DS575 VIDEO 3 VIDEO 2 VIDEO 1 DVD
Pioneer VSX-21 TV/SAT VIDEO 2 VCR 1 DVD/LD
Sony STR-DE825 TV/DBS VIDEO 2 VIDEO 1 DVD/LD
Yamaha RX-V2095 TV/DBS VCR 2 VCR 1 DVD/LD
Brand Model
The products listed at the top of this column connect to the
below listed inputs on the back of the appropriate A/V receiver.
TV/Cable SAT/DBS/DTV VCR DVD
Table 1. A/V receiver back panel input table (Connections vary by model; you may need to test individually)
Samples of various brands of AV Receivers are shown below.
Part ll: Installation
