1.3 Specifications
VIDEO FORMAT NTSC / EIA or PAL / CCIR
HDD STORAGE IDE type, UTMA 66 above, 1 removable HDD supported
RECORD MODE Manual / Alarm / External / Timer
PLAYBACK SEARCHING Date & Time / Event / Alarm searching
RS232 Yes
O.S.D. (On Screen Display) Yes
SECURITY Password protection
VIDEO INPUT 1 video input, composite 1 Vp-p / 75ohm (BNC)
VIDEO OUTPUT 1 video output , composite 1 Vp-p/75ohm (BNC)
VIDEO RESOLUTION 720 x 576 (PAL), 720 x 486 (NTSC)
VIDEO COMPRESSION Wavelet
DISPLAY REFRESH RATE 60 ips (NTSC), 50 ips (PAL)
RECORD REFRESH RATE 60 ips (NTSC), 50 ips (PAL)
ALARM INPUT TTL input, High (5V), Low (GND)
ALARM OUTPUT COM, NO, NC
VIDEO LOSS DETECTION Yes
TIME DISPLAY FORMAT Yes
POWER SOURCE AC90~240V switching adaptor
POWER CONSUMPTION < 27W
DIMENSION 432 x 311x 76mm (W x L x H)
WEIGHT 5. 2 kgs
OPERATION TEMPERATURE 10 ~ 40°C
Specifications are subject to change without notice.
