Multi-Tech Systems MT5634ZPW-PCI - Manual (Page 53)

MT5634ZPW-PCI 53
3 AT Commands, S-Registers and Result Codes
Terse Verbose Description
77* CONNECT 46000 Connected at 46000 bps
78* CONNECT 48000 Connected at 48000 bps
79* CONNECT 50000 Connected at 50000 bps
80* CONNECT 52000 Connected at 52000 bps
81* CONNECT 54000 Connected at 54000 bps
82* CONNECT 56000 Connected at 56000 bps
88 DELAYED Delay is in effect for the dialed
number
89 BLACKLISTED Dialed number is blacklisted
90 BLACKLIST FULL Blacklist is full
* EC is added to these Result Codes when the extended Result Codes configuration
option is enabled. EC is replaced by one of the following codes, depending on the
type of error control connection: V42bis (V.42 error control [LAP-M] and V.42bis
data compression); V42 (V.42 error control [LAP-M] only); MNP5 (MNP 4 error
control and MNP 5 data compression); MNP4 (MNP 4 error control only); NoEC
(No error control protocol).
