Sm-2150/vhf exploded view parts list, Sm-2450/uhf exploded view parts list, Page-69- december 98 – Maxon Telecom FM Mobile radio SM-2000 User Manual
Page 73
Page-69-
December 98
REF #
PART #
DESCRIPTION
QTY
1
801-282-A
E.S.C NORYL N190J-7002
1
2
905-510
FELT 30-R16.5 (2) XT0.3 FELT BLK
1
3
795-654
OVERLAY LEXAN T0.5
1
4
826-137
KNOB (FOR VOL) ABS 94HB BLK
1
5
826-120
KNOB (FOR CH) ABS 94HB BLK
1
6
650-346
NUT RING (FOR VOL) M7X0.75 (P) &9.9 BSBM
1
7
650-335
NUT RING (FOR CH) M9X0.75 (P) &11 BSBM
1
8
661-701
WASHER (FOR VOL) T0.5 SPC
1
9
662-901
WASHER (FOR CH) 13X9.3XT0.5 SPC
1
10
894-650
RING (FOR VOL) &10X&6.9XT0.8 SILI.RUBB BLK
1
11
895-095
RING (FOR CH) &9.3X&12.5 CR BLK
1
12
611-388
(+) MACHINE SCREW (FH) M3X8 (+) FH BLK
2
13
895-040
KEY PAD SILICONE RUBBER
1
14
420-709-9
JACK MODULAR 1130-662
1
15
650-050-0003
CONTROL HEAD P.C.B. ASSY.
1
16
420-108-4A
SPEAKER 4 OHM 5.0W 71MM PB7401A3Y26
1
17
623-034
(+) TAPPING SCREW (PH) T3X6-1S (+) PH ZN-PLAT
3
18
853-078
POST BSBM NI-PLAT
1
19
752-732
PLATE (ESC MTG) SPC T2
1
20
613-174
(+) MACHINE SCREW (FH) M3X5 (+) FH NI-PLAT
1
21
622-039
(+) TAPPING SCREW (BH) T2X6-1S (+) BH ZN-PLAT
2
22
895-044
GASKET (ESC) CR BLK
1
23
702-416-AB
FRAME ALDC12 (SM-2450)
1
24
623-760
(+) TAPPING SCREW (BH) T3X18-2S (+) BH NI-PLAT
2
25
427-411-4
WIRE EMI GASKET 43SM15 (SM-2450)
1
26
427-411-4A
WIRE EMI GASKET 43SM20 (SM-2450)
1
27
772-181
SHIELD CAN SPTE T0.3
1
28
723-844
BRACKET TR SK5 T0.5 NI-PLAT
2
29
895-047
GASKET (EXT JACT) CR BLK
1
30
613-040-S
(+) MACHINE SCREW (PH) M3X6 (+) PH ZN-PLAT 1
12
31
650-000-0001
MAIN P.C.B. ASSY. SM-2150/VHF
1
32
772-298
SHIELD COVER SPTE T0.5
1
33
752-729
CLIP (FOR TR) SUS304 T0.5
1
34
772-243
SHIELD CAN NSP T0.3
1
35
895-041
RING CR BLK
1
36
421-677-7
CONNECTOR BOX SOCKETBCS-110-P-D-HE
1
37
772-179
SHIELD CASE (FOR VCO)
1
38
613-755-SF
(+) MACHINE SCREW (PH) M3X7 (+) PH NI-PLAT
4
39
895-043
GASKET (BRKT) CR BLK
1
40
723-823
BRACKET ALDC12
1
41
612-289
(+) MACHINE SCREW (BH) M2X5 (+) BH BLK
6
42
504-367-B
2P PLUG ASS’Y SH-50101 (SM-2450)
1
43
719-020
COVER TOP ALDC12
1
44
895-075
RUBBER WASHER &6.2X&3.1XT0.5 N.B.R BLK
4
45
660-449
WASHER 6X3.2X0.5T SPC NI-PLAT
4
46
613-764
(+) MECHINE SCREW (PH) M3X20 (+) PH SUS
4
47
893-700
FOOT &11X5 RUBB.STIC.
4
48
613-369
(+) MACHINE SCREW (BH) M3X15 (+) BH ZN-PLAT
1
49
508-085-A
MIC BRACKET ASS’Y
1
50
660-449
WASHER 6X3.2X0.5T SPC NI-PLAT
2
51
662-310
WASHER SPRING M3 NI-PLAT
2
52
613-299
(+) MACHINE SCREW (BH) M3X6 (+) BH NI-PLAT
2
53
723-834
BRACKET SPC T2.0
1
54
600-051
SECURING SCREW M6X9 (P:1) BLK
2
55
661-605
WASHER FLAT M6 ZN-PLAT
2
56
662-606
WASHER SPRING M6 ZN-PLAT
2
57
625-007
(+) TAPPING SCREW (TH) T5X12-1S (+) TH ZN-PLAT
2
58
772-241
SHIELD PLATE SPTE T0.3
1
59
772-242
SHIELD CAN SPTE T0.5
1
60
772-132-A
SHIELD CAN (FR-P) NSP T0.2
1
61
752-769
FINGER STRIP SUS304 T0.3
1
62
895-247
CAP (FOR EXT. JACK)
1
63
662-305
WASHER SPRING M3 ZN-PLAT
4
SM-2150/VHF EXPLODED VIEW PARTS LIST
REF #
PART #
DESCRIPTION
QTY
1
801-282-A
E.S.C NORYL N190J-7002
1
2
905-510
FELT 30-R16.5 (2) XT0.3 FELT BLK
1
3
795-654
OVERLAY LEXAN T0.5
1
4
826-137
KNOB (FOR VOL) ABS 94HB BLK
1
5
826-120
KNOB (FOR CH) ABS 94HB BLK
1
6
650-346
NUT RING (FOR VOL) M7X0.75 (P) &9.9 BSBM
1
7
650-335
NUT RING (FOR CH) M9X0.75 (P) &11 BSBM
1
8
661-701
WASHER (FOR VOL) T0.5 SPC
1
9
662-901
WASHER (FOR CH) 13X9.3XT0.5 SPC
1
10
894-650
RING (FOR VOL) &10X&6.9XT0.8 SILI.RUBB BLK
1
11
895-095
RING (FOR CH) &9.3X&12.5 CR BLK
1
12
611-388
(+) MACHINE SCREW (FH) M3X8 (+) FH BLK
2
13
895-040
KEY PAD SILICONE RUBBER
1
14
420-709-9
JACK MODULAR 1130-662
1
15
650-050-0003
CONTROL HEAD P.C.B. ASSY.
1
16
420-108-4A
SPEAKER 4 OHM 5.0W 71MM PB7401A3Y26
1
17
623-034
(+) TAPPING SCREW (PH) T3X6-1S (+) PH ZN-PLAT
3
18
853-078
POST BSBM NI-PLAT
1
19
752-732
PLATE (ESC MTG) SPC T2
1
20
613-174
(+) MACHINE SCREW (FH) M3X5 (+) FH NI-PLAT
1
21
622-039
(+) TAPPING SCREW (BH) T2X6-1S (+) BH ZN-PLAT
2
22
895-044
GASKET (ESC) CR BLK
1
23
702-416-AB
FRAME ALDC12 (SM-2450)
1
24
623-760
(+) TAPPING SCREW (BH) T3X18-2S (+) BH NI-PLAT
2
25
427-411-4
WIRE EMI GASKET 43SM15 (SM-2450)
1
26
427-411-4A
WIRE EMI GASKET 43SM20 (SM-2450)
1
27
772-181
SHIELD CAN SPTE T0.3
1
28
723-844
BRACKET TR SK5 T0.5 NI-PLAT
2
29
895-047
GASKET (EXT JACT) CR BLK
1
30
613-040-S
(+) MACHINE SCREW (PH) M3X6 (+) PH ZN-PLAT 1
11
31
650-000-0002
MAIN P.C.B. ASSY. SM-2450/UHF
1
32
771-989
SHIELD COVER SPTE T0.5
1
33
752-729
CLIP (FOR TR) SUS304 T0.5
1
34
772-243
SHIELD CAN NSP T0.3
1
35
895-041
RING CR BLK
1
36
421-677-7
CONNECTOR BOX SOCKETBCS-110-P-D-HE
1
37
772-179
SHIELD CASE (FOR VCO)
1
38
613-755-SF
(+) MACHINE SCREW (PH) M3X7 (+) PH NI-PLAT
4
39
895-043
GASKET (BRKT) CR BLK
1
40
723-823
BRACKET ALDC12
1
41
612-289
(+) MACHINE SCREW (BH) M2X5 (+) BH BLK
6
42
504-367-B
2P PLUG ASS’Y SH-50101 (SM-2450)
1
43
719-020
COVER TOP ALDC12
1
44
895-075
RUBBER WASHER &6.2X&3.1XT0.5 N.B.R BLK
4
45
660-449
WASHER 6X3.2X0.5T SPC NI-PLAT
4
46
613-764
(+) MECHINE SCREW (PH) M3X20 (+) PH SUS
4
47
893-700
FOOT &11X5 RUBB.STIC.
4
48
613-369
(+) MACHINE SCREW (BH) M3X15 (+) BH ZN-PLAT
1
49
508-085-A
MIC BRACKET ASS’Y
1
50
660-449
WASHER 6X3.2X0.5T SPC NI-PLAT
2
51
662-310
WASHER SPRING M3 NI-PLAT
2
52
613-299
(+) MACHINE SCREW (BH) M3X6 (+) BH NI-PLAT
2
53
723-834
BRACKET SPC T2.0
1
54
600-051
SECURING SCREW M6X9 (P:1) BLK
2
55
661-605
WASHER FLAT M6 ZN-PLAT
2
56
662-606
WASHER SPRING M6 ZN-PLAT
2
57
625-007
(+) TAPPING SCREW (TH) T5X12-1S (+) TH ZN-PLAT
2
58
772-241
SHIELD PLATE SPTE T0.3
1
59
772-242
SHIELD CAN SPTE T0.5
1
60
772-132-A
SHIELD CAN (FR-P) NSP T0.2
1
61
752-769
FINGER STRIP SUS304 T0.3
1
62
895-247
CAP (FOR EXT. JACK)
1
63
662-305
WASHER SPRING M3 ZN-PLAT
4
SM-2450/UHF EXPLODED VIEW PARTS LIST
