MAXON SM-2000 MOBILE
650-000-0001 SM-2150/VHF MAIN BOARD
Page-36-
December 98
REF # DESCRIPTION PART #
Q550 TRANSISTOR 202-113-1
Q551 TRANSISTOR 202-113-1
Q552 TRANSISTOR 202-113-1
Q553 TRANSISTOR 202-113-1
R186 CHIP RESISTOR 47K 060-473-2Z
R401 CHIP RESISTOR 680K 060-684-6Z
R402 CHIP RESISTOR 47K 060-473-2Z
R403 CHIP RESISTOR 10K 060-103-8Z
R404 CHIP RESISTOR 56K 060-563-0Z
R405 CHIP RESISTOR 7.5K 060-752-4Z
R406 CHIP RESISTOR 18K 060-183-0Z
R407 CHIP RESISTOR 330K 060-334-0Z
R408 CHIP RESISTOR 3.3K 060-332-8Z
R410 CHIP RESISTOR 220K 060-224-4Z
R411 CHIP RESISTOR 100K 060-104-9Z
R412 CHIP RESISTOR 39K 060-393-3Z
R414 CHIP RESISTOR 8.2K 060-822-4Z
R415 CHIP RESISTOR 8.2K 060-822-4Z
R416 CHIP RESISTOR 220K 060-224-4Z
R417 CHIP RESISTOR 8.2K 060-822-4Z
R418 CHIP RESISTOR 8.2K 060-822-4Z
R419 CHIP RESISTOR 47K 060-473-2Z
R420 CHIP RESISTOR 10K 060-103-8Z
R421 CHIP RESISTOR 10K 060-103-8Z
R422 CHIP RESISTOR 43K 060-433-6Z
R423 CHIP RESISTOR 47K 060-473-2Z
R424 CHIP RESISTOR 560 060-561-8Z
R425 CHIP RESISTOR 10K 060-103-8Z
R426 CHIP RESISTOR 47K 060-473-2Z
R427 CHIP RESISTOR 39K 060-393-3Z
R428 CHIP RESISTOR 20K 060-203-5Z
R429 CHIP RESISTOR 100K 060-104-9Z
R430 CHIP RESISTOR 10K 060-103-8Z
R431 CHIP RESISTOR 22K 060-223-3Z
R433 CHIP RESISTOR 47K 060-473-2Z
R434 CHIP RESISTOR 47K 060-473-2Z
R435 CHIP RESISTOR 47K 060-473-2Z
R436 CHIP RESISTOR 22K 060-223-3Z
R437 CHIP RESISTOR 4.7K 060-472-1Z
R438 CHIP RESISTOR 4.7K 060-472-1Z
R439 CHIP RESISTOR 47K 060-473-2Z
R440 CHIP RESISTOR 1M 060-105-0Z
R441 CHIP RESISTOR 43K 060-433-6Z
R442 CHIP RESISTOR 33K 060-333-9Z
R443 CHIP RESISTOR 20K 060-203-5Z
R444 CHIP RESISTOR 220K 060-224-4Z
R445 CHIP RESISTOR 120K 060-124-6Z
R446 CHIP RESISTOR 82K 060-823-5Z
REF # DESCRIPTION PART #
R447 CHIP RESISTOR 120K 060-124-6Z
R448 CHIP RESISTOR 220K 060-224-4Z
R449 CHIP RESISTOR 820 060-821-3Z
R450 CHIP RESISTOR 22K 060-223-3Z
R451 CHIP RESISTOR 2.2K 060-222-2Z
R452 CHIP RESISTOR 1M 060-105-0Z
R453 CHIP RESISTOR 3K 060-302-1Z
R454 CHIP RESISTOR 4.7K 060-472-1Z
R455 CHIP RESISTOR 3.6K 060-362-5Z
R456 CHIP RESISTOR 27K 060-273-8Z
R457 CHIP RESISTOR 47K 060-473-2Z
R458 CHIP RESISTOR 47K 060-473-2Z
R459 CHIP RESISTOR 2.4K 060-242-0
R460 CHIP RESISTOR 470 060-471-0Z
R461 CHIP RESISTOR 470 060-471-0Z
R462 CHIP RESISTOR 47K 060-473-2Z
R463 CHIP RESISTOR 47K 060-473-2Z
R464 CHIP RESISTOR 47K 060-473-2Z
R465 CHIP RESISTOR 47K 060-473-2Z
R466 CHIP RESISTOR 100K 060-104-9Z
R469 CHIP RESISTOR 10K 060-103-8Z
R470 CHIP RESISTOR 30K 060-303-2Z
R471 CHIP RESISTOR 36K 060-363-6Z
R472 CHIP RESISTOR 30K 060-303-2Z
R473 CHIP RESISTOR 4.7K 060-472-1Z
R474 CHIP RESISTOR 360K 060-364-7
R490 CHIP RESISTOR 47K 060-473-2Z
R550 CHIP RESISTOR 7.5K 060-752-4Z
R551 CHIP RESISTOR 27K 060-273-8Z
R552 CHIP RESISTOR 27K 060-273-8Z
R553 CHIP RESISTOR 7.5K 060-752-4Z
R554 CHIP RESISTOR 2.2K 060-222-2Z
R555 CHIP RESISTOR 4.7K 060-472-1Z
R556 CHIP RESISTOR 2.2K 060-222-2Z
R559 CHIP RESISTOR 470 060-471-0Z
RLK3 CHIP RESISTOR 0 060-000-8Z
RLK4 CHIP RESISTOR 0 060-000-8Z
RLK5 CHIP RESISTOR 0 060-000-8Z
RLK7 CHIP RESISTOR 0 060-000-8Z
RLK8 CHIP RESISTOR 0 060-000-8Z
RLK10 CHIP RESISTOR 0 060-000-8Z
RLK11 CHIP RESISTOR 0 060-000-8Z
RLK12 CHIP RESISTOR 0 060-000-8Z
RLK13 CHIP RESISTOR 0 060-000-8Z
RLK14 CHIP RESISTOR 0 060-000-8Z
RV402 RES.CHIP SEMIFIXED 22K 067-223-8Y
RV403 RES.CHIP SEMIFIXED 47K 067-473-7Y
X401 CRYSTAL 262-228-0Z
DIGITAL SECTION (continued)
Digital Parts Common on Both VHF & UHF
