MAXON SM-2000 MOBILE
650-000-0002 SM-2450/UHF MAIN BOARD
Page-44-
December 98
REF # DESCRIPTION PART #
FRONT-END PCB ASSEMBLY (REFER TO BAND CHART)
ANT1 CONNECTOR ANT 422-907-0
ANT1 CONNECTOR SW-1456(BNC-R) 421-655-7
ANT1 PIN CU &1.1X13(101-01) 860-129
C101 CHIP CERAMIC 220PF 132-220-2Y
C102 CHIP CERAMIC 220PF 132-220-2Y
C103 CHIP CERAMIC 220PF 132-220-2Y
C104 CHIP CERAMIC 220PF 132-220-2Y
C105 CHIP CERAMIC 5PF 135-010-4Y
C106 CHIP CERAMIC 470PF 134-761-4Y
C107 CHIP CERAMIC 0.1UF 130-170-0Y
C108 CHIP CERAMIC 220PF 132-220-2Y
C109 CHIP CERAMIC 220PF 132-220-2Y
C110 CHIP CERAMIC 0.001UF 130-A17-6Y
C113A POLY CAPACITOR 0.33UF 120-313-6
C114 MYLAR CAPACITOR 0.01UF 111-008-7Z
C115 CHIP CERAMIC 220PF 132-220-2Y
C118 CHIP CERAMIC 4.7PF 134-767-0Y
C119 CHIP CERAMIC 15PF 131-511-0Y
C120 MYLAR CAPACITOR 0.01UF 111-008-7Z
C121 CHIP CERAMIC 220PF 132-220-2Y
C122 CHIP CERAMIC 0.1UF 130-170-0Y
C125 CHIP TANTALUM 1UF 141-036-1Z
C126 CHIP CERAMIC 220PF 132-220-2Y
C127 CHIP CERAMIC 470PF 134-761-4Y
C128 CHIP CERAMIC 0.001UF 130-A17-6Y
C129 CHIP CERAMIC 0.1UF 130-170-0Y
C131 CHIP CERAMIC 220PF 132-220-2Y
C137 CHIP CERAMIC 68PF 136-816-5Y
C138 CHIP CERAMIC 2.2PF 132-266-4Y
C139 CHIP CERAMIC 220PF 132-220-2Y
C140 CHIP CERAMIC 47PF 134-722-1Y
C141 CHIP CERAMIC 5PF 135-010-4Y
C142 CHIP CERAMIC 12PF 131-208-7Y
C143 CHIP CERAMIC 220PF 132-220-2Y
C144 CHIP CERAMIC 0.5PF 130-504-9Y
C145 CHIP CERAMIC 0.001UF 130-A17-6Y
C146 CHIP CERAMIC 12PF 131-208-7Y
C147 ELECT CAPACITOR 47UF 104-713-2
C148 CHIP CERAMIC 220PF 132-220-2Y
C149 CHIP CERAMIC 220PF 132-220-2Y
C150 CHIP CERAMIC 220PF 132-220-2Y
C151 CHIP CERAMIC 470PF 134-761-4Y
C152 ELECT CAPACITOR 2200UF 102-278-6
C155 CHIP CERAMIC 2.2PF 132-266-4Y
C156 CHIP CERAMIC 47PF 134-722-1Y
C157 CHIP CERAMIC 5.6PF 135-627-2Y
C159 CHIP CERAMIC 6PF 136-005-5Y
C160 CHIP CERAMIC 0.001UF 130-A17-6Y
C162 CHIP CERAMIC 3.3PF 133-321-5Y
REF # DESCRIPTION PART #
C163 CHIP CERAMIC 6PF 136-005-5Y
C164 CHIP CERAMIC 12PF 131-208-7Y
C165 CHIP CERAMIC 6PF 136-005-5Y
C167 CHIP CERAMIC 82PF 138-210-3Y
C168 CHIP CERAMIC 0.001UF 130-A17-6Y
C169 CHIP CERAMIC 47PF 134-722-1Y
C172 CHIP CERAMIC 15PF 131-511-0Y
C173 CHIP CERAMIC 56PF 135-613-9Y
C174 CHIP CERAMIC 3.3PF 133-321-5Y
C175 CHIP CERAMIC 20PF 132-012-1Y
C176 CHIP CERAMIC 39PF 133-932-7Y
C177 CHIP CERAMIC 0.001UF 130-A17-6Y
C178 CHIP CERAMIC 0.001UF 130-A17-6Y
C179 CHIP CERAMIC 82PF 138-210-3Y
C180 CHIP CERAMIC 0.01UF 130-172-2Y
C181 DIP TANTALUM 10UF 141-012-9Z
C182 CHIP CERAMIC 0.001UF 130-A17-6Y
C183 CHIP CERAMIC 47PF 134-722-1Y
C184 CHIP CERAMIC 30PF 133-010-4Y
C185 CHIP CERAMIC 15PF 131-511-0Y
C186 CHIP CERAMIC 0.1UF 130-A60-4Y
C187 CHIP CERAMIC 0.1UF 130-A60-4Y
C188 CHIP CERAMIC 220PF 132-220-2Y
C189 CHIP CERAMIC 0.1UF 130-170-0Y
C190 CHIP CERAMIC 0.033UF 130-314-5Y
C191 CHIP CERAMIC 0.1UF 130-A60-4Y
C192 CHIP CERAMIC 0.033UF 130-314-5Y
C193 CHIP CERAMIC 0.1UF 130-A60-4Y
C194 CHIP CERAMIC 0.0033UF 130-315-6Y
C195 CHIP CERAMIC 10PF 131-039-1Y
C196 CHIP CERAMIC 0.01UF 130-172-2Y
C197 CHIP CERAMIC 47PF 134-722-1Y
C198 CHIP CERAMIC 0.001UF 130-A17-6Y
C199 CHIP CERAMIC 12PF 131-208-7Y
C200 CHIP CERAMIC 0.1UF 130-A60-4Y
C201 CHIP CERAMIC 0.01UF 130-172-2Y
C202 CHIP CERAMIC 0.01UF 130-172-2Y
C203 CHIP CERAMIC 0.001UF 130-A17-6Y
C204 CHIP CERAMIC 6PF 136-005-5Y
C207 CHIP CERAMIC 0.001UF 130-A17-6Y
C209 CHIP CERAMIC 0.1UF 130-A60-4Y
C210 MYLAR CAPACITOR 0.022UF 112-211-8Z
C211 CHIP CERAMIC 0.01UF 130-172-2Y
C212 CHIP CERAMIC 0.01UF 130-172-2Y
C214 CHIP CERAMIC 220PF 132-220-2Y
C216 CHIP CERAMIC 220PF 132-220-2Y
C217 CHIP CERAMIC 220PF 132-220-2Y
C218 ELECT CAPACITOR 10UF 101-025-9
C218 ELECT CAPACITOR 10UF 101-025-9
C219 CHIP CERAMIC 220PF 132-220-2Y
