PARTS LIST COMMON TO SM-2000
MAXON SM-2000 MOBILE
PARTS LIST COMMON TO SM-2000
Page-34-
December 98
REF # DESCRIPTION PART #
650-100-0002 TCXO PCB ASSY. (SEE NOTE 1)
650-090-0003 MA-4472 MIC ASSY. (SEE NOTE 1)
NOTES:
1. Components are not available, assembly is non-repairable.
REF # DESCRIPTION PART #
650-050-0003 CONTROL HEAD PCB ASSY.
CON1 HEADER PIN Z422-492-1
CON801 JACK MODULAR 420-709-9
C801 CHIP CERAMIC 47PF 134-722-1Z
C802 CHIP CERAMIC 47PF 134-722-1Z
C803 CHIP CERAMIC 47PF 134-722-1Z
C804 CHIP CERAMIC 47PF 134-722-1Z
C805 CHIP CERAMIC 47PF 134-722-1Z
C806 CHIP CERAMIC 47PF 134-722-1Z
C807 CHIP CERAMIC 47PF 134-722-1Z
C808 CHIP CERAMIC 47PF 134-722-1Z
C809 CHIP CERAMIC 47PF 134-722-1Z
C815 DISK CERAMIC (FOR SP1) 470PF 134-710-8
C821 CHIP CERAMIC 0.001UF 130-A17-6Z
C823 ELECT CAPACITOR 10UF 101-025-9
D801 DIODE SI CHIP KDS193 243-052-6
D802 DIODE SI CHIP KDS193 243-052-6
D803 DIODE SI CHIP KDS193 243-052-6
D804 DIODE SI CHIP KDS184S 243-051-5
D807 DIODE ZENER 241-099-9
D808 DIODE ZENER 241-099-9
D810 DIODE ZENER 241-099-9
D811 DIODE ZENER 241-099-9
LED1 LED LAMP GRN 3 V 75MW 251-160-3
LED2 LED LAMP GRN 3 V 75MW 251-160-3
LED3 LED LAMP GRN 3 V 75MW 251-160-3
LED4 LED LAMP GRN 3 V 75MW 251-160-3
LED5 LED LAMP RED/GRN 3 V 251-168-1
Q821 TRANSISTOR 202-106-5
Q822 TRANSISTOR 202-106-5
R801 CHIP RESISTOR 470 OHM 060-471-0Z
R821 CHIP RESISTOR 22 OHM 060-220-0Z
R822 CHIP RESISTOR 4.7K 060-472-1Z
SP1 SPEAKER 4 OHM 420-108-4A
SW3 SW PUSH 432-063-7
SW4 TACT SWITCH 436-038-8
SW405 SW ROTARY 430-070-5
VR801 VR 20KA 450-523-5
HOLDER(LED) 892-390
HOLDER(LED) 892-540
P.C.B. CONTROL HEAD 416-988-C
