MAXON SM-2000 MOBILE
650-000-0001 SM-2150/VHF MAIN BOARD
Page-39-
December 98
REF # DESCRIPTION PART #
C247 CHIP CERAMIC 220PF 132-220-2Y
C248 CHIP CERAMIC 27PF 132-714-2Y
C250 ELECT CAPACITOR 47UF 104-713-2
C251 CHIP CERAMIC 470PF 134-761-4Y
C252 CHIP CERAMIC 0.001UF 130-A17-6Y
C253 CHIP CERAMIC 75PF 137-504-4Y
C255 CHIP CERAMIC 470PF 134-761-4Y
C256 CHIP CERAMIC 75PF 137-504-4Y
C257 CHIP CERAMIC 0.01UF 130-172-2Y
C258 CHIP CERAMIC 470PF 134-761-4Y
C259 CHIP CERAMIC 0.01UF 130-172-2Y
C260 CHIP CERAMIC 0.01UF 130-172-2Y
C261 CHIP CERAMIC 39PF 133-937-2Y
C262 CHIP CERAMIC 75PF 137-512-1Z
C263 CHIP CERAMIC 0.001UF 130-A17-6Y
C264 CHIP CERAMIC 0.1UF 130-A60-4Y
C265 CHIP CERAMIC 0.001UF 130-A17-6Y
C266 CHIP CERAMIC 0.001UF 130-A17-6Y
C267 CHIP CERAMIC 0.001UF 130-A17-6Y
C268 CHIP CERAMIC 22PF 132-225-7Z
C271 CHIP CERAMIC 0.001UF 131-025-8Y
C272 CHIP CERAMIC 15PF 131-539-6Z
C274 CHIP CERAMIC 0.001UF 131-025-8Y
C279 ELECT CAPACITOR 10UF 101-025-9
C282 CHIP CERAMIC 470PF 134-761-4Y
C285 CHIP CERAMIC 0.001UF 130-A17-6Y
C286 CHIP CERAMIC 0.001UF 130-A17-6Y
C287 CHIP CERAMIC 0.001UF 130-A17-6Y
C288 CHIP CERAMIC 220PF 132-220-2Y
C289 CHIP CERAMIC 82PF 138-210-3Y
C290 CHIP CERAMIC 0.047UF 130-424-0Y
C292 CHIP CERAMIC 220PF 132-220-2Y
C295 CHIP CERAMIC 0.01UF 130-172-2Y
C296 CHIP CERAMIC 47PF 134-722-1Y
C297 CHIP CERAMIC 47PF 134-722-1Y
C298 CHIP CERAMIC 22PF 132-216-9Y
C299 CHIP CERAMIC 47PF 134-722-1Y
C300 CHIP CERAMIC 470PF 134-761-4Y
C301 CHIP CERAMIC 220PF 132-220-2Y
C302 CHIP CERAMIC 0.1UF 130-170-0Y
C310 CHIP CERAMIC 30PF 133-010-4Y
C311 CHIP CERAMIC 0.001UF 131-025-8Y
C312 CHIP CERAMIC 7PF 137-011-5Y
C313 CHIP CERAMIC 180PF 131-847-4Y
C314 CHIP CERAMIC 180PF 131-847-4Y
C315 CHIP CERAMIC 15PF 131-539-6Z
C351 CHIP CERAMIC 0.001UF 130-A17-6Y
C352 CHIP CERAMIC 7PF 137-007-1Y
C353 CHIP CERAMIC 9PF 139-003-8Y
REF # DESCRIPTION PART #
C355 CHIP CERAMIC 1.2PF 131-216-4Y
C356 CHIP CERAMIC 4PF 134-007-7Y
C359 CHIP CERAMIC 0.001UF 130-A17-6Y
C360 CHIP CERAMIC 2PF 132-011-0Y
C361 CHIP CERAMIC 0.001UF 130-A17-6Y
C362 CHIP CERAMIC 0.001UF 130-A17-6Y
C363 CHIP CERAMIC 0.001UF 130-A17-6Y
C364 CHIP CERAMIC 0.001UF 130-A17-6Y
C369 CHIP CERAMIC 1PF 131-030-2Y
C370 CHIP CERAMIC 0.001UF 130-A17-6Y
C371 CHIP CERAMIC 0.1UF 130-A60-4Y
C372 CHIP CERAMIC 0.01UF 130-172-2Y
C373 CHIP TANTALUM 3.3UF 143-312-0Z
C374 CHIP CERAMIC 0.001UF 130-A17-6Y
C375 CHIP CERAMIC 0.001UF 130-A17-6Y
C376 CHIP CERAMIC 0.1UF 130-A60-4Y
CF101 FILTER CRYSTAL 271-053-6
CF103 FILTER CERAMIC 270-007-0Z
CF104 FILTER CERAMIC 270-027-8Z
D102 DIODE SI CHIP 243-051-5
D103 DIODE 243-012-0
D104 DIODE 243-012-0
D106 DIODE SI CHIP 243-052-6
D107 DIODE SCHOTTKY CHIP 249-005-4
D108 DIODE CHIP 243-081-2
D120 DIODE CHIP 243-087-8
D124 DIODE RECTIFIER 245-008-7Z
D125 DIODE SI CHIP 243-052-6
D126 DIODE SWITCHING 243-063-6
D127 DIODE PIN 243-073-5
D128 DIODE SWITCHING 243-063-6
D129 DIODE SI CHIP 243-052-6
D351 DIODE 243-054-8
D352 DIODE 243-054-8
D353 DIODE 243-054-8
FB101 FERITE BEAD 320-423-8
IC101 I.C PLL 220-131-3
IC102 DBM MIXER MODULE 220-375-7
IC104 I.C OP AMP 231-064-4
IC105 I.C REGULATOR 220-378-0
IC107 I.C REGULATOR 222-013-0A
IC108 I.C 229-289-8
IC109 I.C POWER FM IF 223-421-0
IC113 I.C OP AMP 231-064-4
J1 JACK MINIATURE 420-728-5
L107 COIL CHIP 1UH 310-657-0
L108 COIL CHIP 1.0UH 311-079-3
L110 COIL CHIP 47NH 310-861-7
L111 COIL CHIP 0.15UH 310-706-1
