MAXON SM-2000 MOBILE
650-000-0001 SM-2150/VHF MAIN BOARD
Page-40-
December 98
REF # DESCRIPTION PART #
L113 COIL SPRING 310-794-0
L115 COIL SPRING 310-793-9
L116 COIL SPRING 310-224-2
L117 COIL SPRING 310-368-9
L118 COIL CHOKE 1K 310-218-7
L119 COIL CHIP 0.15UH 310-706-1
L120 COIL CHOKE 1K 310-218-7
L121 COIL SPRING 310-275-8
L122 COIL ASS’Y 509-772
L123 COIL CHIP 47NH 310-861-7
L124 COIL CHIP 0.68UH 310-711-5
L125 COIL SPRING 310-368-9
L126 COIL SPRING 310-627-3
L127 COIL SPRING 311-224-7
L128 COIL SPRING 311-214-8
L129 COIL SPRING 310-536-4
L130 COIL SPRING 311-214-8
L131 COIL SPRING 311-214-8
L132 COIL SPRING 311-305-7
L134 COIL ASS’Y 509-772
L135 COIL ASS’Y 509-013
L225 COIL AXIAL 2.2UH 310-378-7
L226 COIL CHIP 1UH 310-657-0
L227 COIL CHIP 220UH 310-862-8Y
L228 COIL AXIAL 1MH 310-381-0
L229 COIL AXIAL 1MH 310-381-0
L351 COIL CHIP 1.0UH 311-079-3
L352 COIL CHIP 0.82UH 311-078-2
L354 COIL CHIP 2.2UH 311-083-6
L356 COIL CHIP 311-117-4
L357 COIL CHIP 2.2UH 311-083-6
L358 COIL CHIP 1.0UH 311-079-3
Q101 TRANSISTOR 202-113-1
Q102 TRANSISTOR 202-106-5
Q103 TRANSISTOR 202-106-5
Q104 TRANSISTOR 202-113-1
Q105 TRANSISTOR 218-057-7Z
Q106 TRANSISTOR 203-096-4
Q108 TRANSISTOR 202-095-8Z
Q113 TRANSISTOR 200-003-5
Q114 TRANSISTOR 200-003-5
Q116 TRANSISTOR 203-181-7
Q117 TRANSISTOR 200-045-3
Q118 TRANSISTOR 203-043-6Z
Q120 TRANSISTOR 203-087-6
Q121 TRANSISTOR 202-095-8Z
Q122 TRANSISTOR 203-111-4
Q123 TRANSISTOR 202-095-8Z
Q124 TRANSISTOR 202-113-1
Q125 TRANSISTOR 202-066-2
REF # DESCRIPTION PART #
Q127 TRANSISTOR 202-095-8Z
Q128 BRT 202-092-5
Q130 TRANSISTOR 200-003-5
Q132 TRANSISTOR 202-113-1
Q133 TRANSISTOR 202-113-1
Q134 TRANSISTOR 202-095-8Z
Q135 TRANSISTOR 202-095-8Z
Q137 TRANSISTOR 202-095-8Z
Q139 BRT 202-092-5
Q140 TRANSISTOR 202-095-8Z
Q219 TRANSISTOR 202-095-8Z
Q351 TRANSISTOR 203-116-9
Q352 TRANSISTOR 203-116-9
Q353 TRANSISTOR 202-099-2Z
Q354 TRANSISTOR 202-098-1
Q360 TRANSISTOR 202-113-1
R100 CHIP RESISTOR 2.2K 060-222-2Z
R1001 CHIP RESISTOR 470 060-471-0Z
R101 CHIP RESISTOR 1.8K 060-182-9Z
R102 CHIP RESISTOR 0 060-000-8Z
R103 CHIP RESISTOR 0 060-000-8Z
R104 CHIP RESISTOR 1.8K 060-182-9Z
R105 CHIP RESISTOR 470 060-471-0Z
R106 CHIP RESISTOR 1.8K 060-182-9Z
R107 CHIP RESISTOR 470 060-471-0Z
R108 CHIP RESISTOR 0 060-000-8Z
R110 CHIP RESISTOR 1.2K 060-122-5Z
R111 CHIP RESISTOR 2.7K 060-272-7Z
R112 CHIP RESISTOR 7.5K 060-752-4Z
R113 CHIP RESISTOR 100K 060-104-9Z
R114 CHIP RESISTOR 10K 060-103-8Z
R116 CHIP RESISTOR 10K 060-103-8Z
R117 CHIP RESISTOR 24K 060-243-1Z
R118 CHIP RESISTOR 10K 060-103-8Z
R119 CHIP RESISTOR 10K 060-103-8Z
R130 CHIP RESISTOR 1.2K 060-122-5Z
R131 CHIP RESISTOR 91K 060-913-3Z
R132 CHIP RESISTOR 4.7K 060-472-1Z
R133 CHIP RESISTOR 20K 060-203-5Z
R134 CHIP RESISTOR 6.8K 060-682-4Z
R135 CHIP RESISTOR 39 060-390-8Z
R136 CHIP RESISTOR 2.7K 060-272-7Z
R137 CHIP RESISTOR 2.7K 060-272-7Z
R138 CHIP RESISTOR 470 060-471-0Z
R139 CHIP RESISTOR 22K 060-223-3Z
R140 CHIP RESISTOR 10 060-100-5Z
R141 CHIP RESISTOR 470 060-471-0Z
R142 CHIP RESISTOR 10K 060-103-8Z
R143 CHIP RESISTOR 1.8K 060-182-9Z
R144 CHIP RESISTOR 51 060-510-2
