Specifications
Power Supply
• Operating voltage:
• 12V range (link L2-in place) 7-16 VDC
• 24V range (link L2-cut) 19-30 VDC
• Current consumption:
• CDV100F: 25mA typical
• CDV300R: 50mA, typical (2 LEDs lit)
Inputs
• CANbus:
• SAE J1939 protocol, Input fitted with 120 Ohm terminating resistor, removable by cutting link L1.
Outputs
• Oil pressure gage, coolant temperature gage
• Link selectable for Murphy, VDO or Datcon electric gages
• Tachometer
• Pulsed DC, approximately 121 Hz @ 1500 RPM
General
• Overall dimensions (W x H x D)
• Case: 2.7x3.8x0.9 inch (68x96x22mm) (allow 2 inches (50mm) depth with connector)
• Weight: approximately .18 lbs (80g)
• Environmental sealing
• IP60
• CDV300R: IP65 from front with CDVG gasket (included)
• Operating ambient temperature: -40° F to 185° F (-40°C to +85°C)
• Storage temperature: -67°F to 221°F (-55°C to 105°C)
• Operating Vibration: .02 lbs (10g) (5-2000 Hz)
• Operating Shock: .11 lbs (50g) (3-axis)
