EN-46
1 R(RED)/C R
G(GREEN)/Y
3 B(BLUE)/C B
4 GND
5 GND
6 GND
7 GND
8 GND
9 DDC 5V (*1)
10 GND
11 GND
1 DDC Data (*1)
13 HD/CS
14 VD
15 DDC Clock (*1)
1 - -
TXD IN
3 RXD OUT
4 - -
5 GND -
6 - -
7 - -
8 - -
9 - -
1 5
11
6 10
15
SERIAL (D-SUB 9-pin)
Pin No. Name I/O
COMPUTER/COMPONENT VIDEO IN-1/IN-
(Mini D-SUB 15-pin)
Pin No. Spec.
DVI-D (HDCP)
(DVI-D 4-pin)
Pin No. Spec. Pin No. Spec.
1 TMDS DATA - 13 -
TMDS DATA + 14 +5V Power
3 TMDS DATA Shield 15 Ground (for +5V)
4 - 16 Hot Plug Detect
5 - 17 TMDS DATA 0-
6 DDC Clock 18 TMDS DATA 0+
7 DDC Data 19 TMDS DATA 0 Shield
8 - 0 -
9 TMDS DATA 1- 1 -
10 TMDS DATA 1+ TMDS Clock Shield
11 TMDS DATA 1 Shield 3 TMDS Clock+
1 - 4 TMDS Clock-
17 4
16 9
8 1
Connectors
35
333
59.5
113
84.5
7
Dimension Drawings (unit: mm)
Specifications (continued)
1 5
6 9
(*1 For IN-1 terminal only. )
