PAGE 6 — DCA-180SSV— OPERATION AND PARTS MANUAL — REV. #1 (04/14/10)
DCA-180SSV— SPECIFICATIONS
Table 1. Generator Specifications
Model DCA-180SSV
Type
Revolving field, self ventilated,
open protected type synchronous generator
Armature Connection Star with Neutral
Phase 3
Standby Output 198 KVA (158 KW)
Prime Output 180 KVA (144 KW)
Voltage — 1Ø 120, 127, 139, 240, 254, and 277V
Voltage — 3Ø 208, 220, 240, 416, 440, and 480V
Frequency 60 Hz
Speed 1800 rpm
Power Factor 0.8
Aux. AC Power Single Phase, 60 Hz
Aux. Voltage/Output 120 VAC/ 4.8 Kw (2.4 kW x 2)
Dry Weight 11,136 lbs. (5,050 kg.)
Wet Weight 12,260 lbs. (5,560 kg.)
Table 2. Engine Specifications
Model VOLVO TAD722GE
Type 4 cycle, water-cooled, direct injection, turbo-charged
No. of Cylinders 6 cylinders
Bore x Stroke 5.15 in. x 5.90 in. (131 mm x 150 mm)
Displacement 740.2 cu. in. (12,130 cc)
Starting Electric 24 VDC
Coolant Capacity 11.6 gal. (44 liters)
Lube Oil Capacity 9.2 gal. (35 liters)
Fuel Type #2 Diesel Fuel
Fuel Tank Capacity 129 gal. (490 liters)
Fuel Consumption
11.2 gal. (42.2 L)/hr at full load 8.5 gal. (32.0 L)/hr at 3/4 load
5.9 gal. (22.4 L) at 1/2 load 3.7 gal (14.0 L) at 1/4 load
Battery 12V-150 Ah x 2
