DCA-180SSV— OPERATION AND PARTS MANUAL — REV. #1 (04/14/10) — PAGE 29

1

Maximum Amps
Table 10 shows the

maximum amps the generator can pro-

vide. DO NOT exceed the maximum amps as listed.

How to Read the Output Terminal Gauge.
The AC ammeter and AC voltmeter change-over switches
on the control panel DO NOT effect the generator output.
They are provided to help observe how much power is being
supplied, produced at the UVWO terminals lugs.

When the voltage change-over board is jumpered for

3Ø,

240V operation (See Figures 16 and17), place the

AC Volt-

meter Change-Over Switch (See Figures 18 and 19) to the
W-U position and the

AC Ammeter Change-Over Switch

(Figure 18) to the U or W position to read the output on the
selected leg.

Figure 15. Voltage Change-Over Board

240V Configuration

Figure 16. AC Voltmeter

Change-Over Switch

Figure 17. AC Voltmeter Gauge

(Volt reading on W-U Lug)

Figure 19. AC Ammeter

(Amp reading on U lug)

Figure 18. AC Ammeter

Change-Over Switch

The

ammeter gauge will only

show a reading when the
Output Terminal Lugs are
connected to a load and in use.

NOTE

DCA-180SSV— GENERATOR OUTPUTS/ GAUGE READING
