SEPARATED COMBUSTION BLOWER UNIT HEATERS
15
W
X
F
C
G
M
N
S
O
K
/
16
"
9
5
CC
J
➀
L = C + P (APPROX.)
DD
P
Q x V
R x T
/
8
"
7
4
/
4
"
3
FILTER RACK
(OPTIONAL)
BLOWER
ENCLOSURE
(OPTIONAL)
OVAL COLLAR FITS
6" ROUND PIPE FOR
MODELS BSH 280 & 340 ONLY
A
H
D (OPENING)
BB
E
AA
B
K
➁
GAS SUPPLY
CONNECTION
2
7/
8
"
FF
/
16
"
9
5
/
2
"
1
4
/
8
"
1
3
COMBUSTION AIR
INLET COLLAR
(SIZES 130-225)
COMBUSTION AIR
INLET COLLAR
(SIZES 130 - 225)
3
3/
8
"
3
1/
8
"
EE
4" ROUND FOR
BSH 130 thru 225
MODELS ONLY
The minimum recommended
installation clearance from top and
rear of unit (motor) is six inches.
Clearance to sides is eighteen
inches, and clearance at bottom
should equal “C” dimension shown
in table for each model.
Dimensions (in inches) — BSH
Dimension
BSH 130
BSH 150
BSH 170
BSH 225
BSH 280
BSH 340
A
23-1/2
25-5/8
25-5/8
25-5/8
33-5/8
40
B
35-1/2
40-1/2
40-1/2
40-1/2
40-1/2
40-1/2
C
22
25
25
25
25
25
D
21-1/16
23-3/16
23-3/16
26-3/16
31-3/16
37-1/2
E
20
24
24
24
24
24
F
12-1/2
14-1/2
14-1/2
14-1/2
—
—
G
1
2
2
2
1-5/8
1-5/8
H
19-7/8
22
22
25
30
36-3/8
AA
8
9
9
9
9
9
BB
7-1/2
7-1/2
7-1/2
7-1/2
7-1/2
7-1/2
CC
1
1/8
1/8
1/8
1 3/8
1 3/8
DD
3-1/4
3-1/4
3-1/4
3-1/4
3-5/8
3-5/8
EE
32-9/16
36
36
36
36-1/16
36-1/16
FF
6-1/2
6-1/2
6-1/2
6-1/2
5-7/8
5-7/8
J (Round)
4
4
4
4
6
6
K ➂
3/8-16
3/8-16
3/8-16
3/8-16
3/8-16
3/8-16
Natural Gas Connections
1/2
1/2
1/2
1/2
3/4
3/4
W
—
—
—
—
5
5
X
—
—
—
—
16
16
M
47-3/4
52-3/8
52-3/8
52-3/8
52-3/8
58-1/2
N ➃
21
24-1/2
24-1/2
24-1/2
17-15/16
22-1/16
O
7-1/4
8-1/2
8-1/2
8-1/2
8-1/2
8-1/2
P
30
34
34
34
36
36
Blower
Q (Height)
21-3/8
25
25
25
25
25
Enclosure
Inlet Duct/R (Height)
20
23-3/4
23-5/8
23-5/8
23-5/8
23-5/8
(Accessory)
Filter Rack Width T
27-1/2
32-3/4
32-3/4
32-3/4
42-7/8
42-7/8
Width V
29
34
34
34
44-1/4
44-1/4
S (Ctr. to Ctr. of Blower Mtg. Holes
17-3/8
20-3/8
20-3/8
20-3/8
20-3/8
20-3/8
Motor Pulley Diameter ➄
3
3
3
3
3
3
Standard Blower Pulley Diameter
13
13
13
13
9
9
Approx. Shipping Weight
240
322
322
344
436
510
➀
On blower units L = C + P is distance from front of unit to back of blower enclosure and minimum of distance to wall.
➁
Dimension from rear of unit burner box to center line of gas pipe connection is 6-23/32" for BSH 130 and 6-1/2" for all other models.
➂
BSH 130 through BSH 225 – 4 holes. BSH 280 and BSH 340 – 6 holes.
➃
Distance between mounting hole in unit casing and mounting hole on blower, except on 280 and 340, then distance from rear mounting hole in casing.
➄
Motor pulley is adjustable.
➅
At 65°F ambient and unit fired at full rated input. Max mounting height as measured from bottom of unit, and without deflector hoods.
➆
Note: Ratings shown are for elevations up to 2,000 feet. For elevations above 2,000 feet, ratings should be reduced at the rate of 4% for each 1,000 feet above sea
level. (In Canada see Rating Plate.) Reduction of ratings requires use of high altitude kit.
➇
Data listed is for standard 115-volt, 60-Hertz, single-phase motors. All single phase motors are totally enclosed and thermal overload protected.
Performance — BSH
Outlet
Max. Mtg.
Heat
CFM
Velocity
Air
Height (Ft.)
Throw (Ft.)
Btu/Hr
@ 55°F
@55°F
Temp.
@ 55°F
@ 55°F
Standard Motor Data ➇
Input
Btu/Hr
Temp.
Temp.
CFM
Rise
Temp. Rise
Temp. Rise
Model
➆
Output
Rise
Rise
Range
Range
➅
➅
HP
Amps
RPM
Type
BSH 130
130,000
106,600
1795
682
1161-1795
55-85
11
30
1/4
5.4
1725
SP
BSH 150
150,000
123,000
2071
596
1340-2071
55-85
10
25
1/2
7.8
1725
SP
BSH 170
170,000
139,400
2347
675
1519-2347
55085
11
30
1/2
7.8
1725
SP
BSH 225
225,000
182,250
3068
781
1985-3068
55-85
13
35
3/4
10.2
1725
SP
BSH 280
280,000
229,600
3865
852
2501-3865
55-85
14
40
1
13.2
1725
CP
BSH 340
340,000
275,400
4636
869
3000-4636
55-85
15
40
1
13.2
1725
CP
Note: Mounting heights and throws for BSH models, without ductwork or nozzles, and at a cfm yielding a 55°F
temperature rise are the same as those listed for equivalent size PSH units.
