W6-LI System Board Manual
Chapter 3: Installing the W6-LI
32
Connecting the SCSI Option
The W6-LI can be upgraded to include integrated Ultra
Wide SCSI PCI throughput (up to 40MBytes/sec data
rate). Connectors are provided for Normal (Fast) SCSI
(50-pin connector) and Wide (Ultra Wide) SCSI
(68-pin connector). The Wide SCSI configuration al-
lows up to 15 SCSI peripherals to be connected. The
W6-LI SCSI interface is Plug and Play compliant and is
fully compatible with the PCI 2.0 specification.
Refer to the "Adaptec AHA-2940Ultra/2940Ultra Wide
User's Guide" for information on installing and connect-
ing SCSI devices.
