W6-LI System Board Manual
Memory Configurations
The following tables list the most common memory configu-
rations. The memory available depends on the number of
DIMMs installed.
Table 3-1: Memory Configurations
There is no
need to set
any jumpers.
When you
reboot, the
size and
type of
memory are
automatically
detected.
Chapter 3: Installing the W6-LI
21
Memory Bank 0 Bank 1 Bank 2 Bank 3
8MB 1MBx64/72
16MB 2MBx64/72
16MB 1MBx64/72 1MBx64/72
24MB 2MBx64/72 1MBx64/72
24MB 1MBx64/72 1MBx64/72 1MBx64/72
32MB 2MBx64/72 2MBx64/72
32MB 2MBx64/72 1MBx64/72 1MBx64/72
32MB 4MBx64/72
32MB 1MBx64/72 1MBx64/72 1MBx64/72 1MBx64/72
40MB 2MBx64/72 2MBx64/72 1MBx64/72
40MB 2MBx64/72 1MBx64/72 1MBx64/72 1MBx64/72
40MB 4MBx64/72 1MBx64/72
48MB 2MBx64/72 2MBx64/72 2MBx64/72
48MB 2MBx64/72 2MBx64/72 1MBx64/72 1MBx64/72
48MB 4MBx64/72 2MBx64/72
48MB 4MBx64/72 1MBx64/72 1MBx64/72
56MB 2MBx64/72 2MBx64/72 2MBx64/72 1MBx64/72
56MB 4MBx64/72 2MBx64/72 1MBx64/72
56MB 4MBx64/72 1MBx64/72 1MBx64/72 1MBx64/72
