CAUTION
Driving with the convertible top not
fully locked could damage the
convertible top.
If the red indicator is visible on the
unlock button, the convertible top is not
locked. After locking the convertible
top, verify that the red indicator is not
visible.
Locked position
Unlocked position
Red indicator
NOTE
Make sure the convertible top is
securely locked by pushing up on it. If
it still sounds loose (rattles) after being
locked by the top latch, have it
inspected at an Authorized Mazda
Dealer.
7. Connect the rear window defroster
coupler if it has been disconnected.
NOTE
If the coupler was not plugged in the
rear window defroster would not work.
qTaking Care of the Top
Refer to Convertible Top Maintenance
(page 8-57) for information on taking care
of the convertible top.
Knowing Your Mazda
Doors and Locks
3-45
