6. Standing outside of the vehicle, hold
the convertible top along the center
edge and pull it toward the vehicle rear.
Center edge
NOTE
To lower the convertible top from inside
the vehicle, use the convertible top's
handles.
Convertible top's
handles
7. Continue to move the convertible top
rearward while pressing the rear glass
lightly with your hand.
8. After the convertible top has been
folded down, press the back end of the
folded down convertible top until a
click sound is heard, then the front end.
Lightly rock the retracted convertible
top to make sure it is securely locked.
9. Raise the windblocker if it is needed.
NOTE
The windblocker reduces the amount of
wind coming into the cabin from behind
when driving with the convertible top
opened.
Refer to Windblocker on page 6-48.
Knowing Your Mazda
Doors and Locks
3-43
