ST2010 SerieS SubmerSible pump • operaTion and parTS manual — rev. #3 (12/07/12) — page 9
diMensiOns
ST2010TCul
ST2010, ST2010a, ST2010b, ST2010Cul
Figure 1. ST2010 Series Dimensions
23.82 in.
(605 mm.)
10.23 in.
(260 mm.)
3.14 in.
(80 mm.)
5.11 in.
(130 mm.)
NPT 2
4.52 in.
(115 mm.)
3.54 in.
(90 mm.)
7.08 in.
(180 mm.)
4.37 in.
(111 mm.)
49.21 ft.
(15 m)
16.46 in
(418 mm)
6.7 in
(170 mm) Dia.
49.21 ft
(15m)
