page 8 —ST2010 SerieS SubmerSible pump • operaTion and parTS manual — rev. #3 (12/07/12)

speCifiCatiOns

Table 1. Specifications

model

ST-2010/ST-2010a/

ST-2010Cul

ST-2010b

ST-2010TCul

Type

Submersible Pump

Submersible Trash Pump

Impeller

Cast Ductile Iron

Discharge Size

2.00 in. (51 mm)

Maximum Pumping

Capacity

85 gallons/minute

(322 liters/minute)

85 gallons/minute

(322 liters/minute)

90 gallons/minute

(341 liters/minute)

Max. Solids Diameter

---

1.00 in. (25 mm.)

Max Head

54.7 ft. (16.6 meters)
ST-2010CUL: 50 ft. (15.24 m)

54.7 ft. (16.6 meters)

45 ft. (13.7 meters)

Power

1.0 HP (0.75 kw)

Voltage; Phase

1Ø 115V

1Ø 230V

1Ø 115V

Starting Amps

63 A

30 A

53 A

Running Amps

ST2010: 13.5 A

ST2010A: 13.5 A

ST2010CUL: 11.9A

6.7 A

9.4 A

Control Box (see Note 3)

CB3

CB6

CB3

Thermal Overlaod

Protection

YES

Rotation

CCW (Note 1)

Mechanical Oil seal

Capacity

150 cc. (Note 2)

180 cc. (Note 2)

Check Frequency

Monthly (300 hrs.)

RMP (Speed)

3550 +/- 30

Power Cable Length

50 ft. (15.2 meters)

Dry Net weight

55 lbs. (25 Kg.)

77 lbs. (35 Kg.)

Motor Rotation – Upon start-up, the pump "kicks" in the opposite direction of motor rotation. The correct rotation is counterclockwise (CCW) as viewed from
the impeller end of the pump.

Mechanical Oil Seal – Use a good grade 10 weight non-detergent hydraulic oil (i.e. Shell Turbo 32 or equivalent). Fill oil cavity 75% to 85% full (allow air
space for expansion).

Control Box - Control box (Table 2) may be required for certain pumping applications.

Table 2. Control box Specifications

model no.

voltage Type

ul/CSa listed

Thermal

overload

protection

Float Switch

Capability

CB3

115 VAC, 60 Hz Single-Phase

YES

CB6

230 VAC, 60 Hz Single-Phase

YES
