INSTALLATION
UNPACKING CONTENTS
•
The printer
•
Test ribbon cartridge
•
Roll paper shaft
•
Spacer for 3” paper roll (2 ea.)
•
Spacer for 2.25” paper roll (2 ea.)
•
E -ring (2 ea.)
•
Test paper roll
•
Springy hook plate (mounted)
•
Rear hook
•
Screws to hold springy hook plate (mounted) and rear hook
•
Manual
•
Power adapter with power cord (option)
BASIC MOUNTING
For POSiFLEX PST POS System
First install the springy hook plate and rear hook onto the metal bottom
plate of the POS printer. Unscrew and re-install the springy hook plate in the
way that the two springy hooks come out of the front edge of the metal bottom
plate (they were pointing inward when shipped). Install the rear hook with its
middle hook lock into the metal bottom plate first and screw the rear hook to the
metal bottom plate (ref. Fig. 1). Connect the power cable and the printer cable
(CCBLA-191 for serial interfaced printer or CCBLA-192 for parallel interfaced
printer) in the way illustrated in the section of “CABLE CONNECTIONS”. Push
open the battery cover of PST system and pass the cables through the opening
beside the battery cover on the PST POS system and close the battery cover
