8 MultiModemISI Hybrid Series, ISIHP-2S/2U
Hardware Installation
Intelligent Serial Interface
Hybrid (ISDN/POTS) Cards
( Side View )
International
ISIHP-2S
U.S. Domestic
ISIHP-2U
4. To avoid damaging the ISIHP-2S/2U and your PC, make sure your
computer and any peripheral equipment connected to it are turned
off. The ISIHP-2S/2U can be installed in a Pentium equivalent
PCI bus computer.
5. Remove the cover of your computer as instructed in your
computer’s documentation.
6. Locate the unused PCI slot you will be using for your ISIHP-2S/2U
card and remove the slot cover according to instructions in your
computer’s documentation.
7. Install the ISIHP-2S/2U card in the selected expansion slot in the
same manner as any other add-on card according to your
computer’s documentation.
8. Fasten retaining bracket to the computer chassis and replace the
cover.
9. Connect the ISIHP-2S/2U to your ISDN telephone wall jack with
the provided modular telephone cable.
