18
EJECT
OPEN/
CLOSE
CH
CH
DVD MENU RETURN
CLEAR/
CANCEL
ANGLE/
COUNTER RESET
CLOCK/
COUNTER
PLAY MODE/
SPEED
AUDIO/
AUDIO SELECT
TV/VCR
PLAY
INDEX/SKIP SKIP/INDEX
SLOW PAUSE/STILL
STOP
ZOOM MARKER
VCR/DVD
DISPLAY/CALL
TRACKING/
SET
–
TRACKING/
SET
+
REPEAT A-B
REW/SEARCH SEARCH/F.FWD
POWER
TIMER REC
REC/OTR
SUB TITLE/
ATR
JUMP/
ZERO RETURN
1 2 3
4 5 6
0 7 8 9
SELECT/
ENTER
SETUP/
VCR MENU
TOP MENU
INPUT SELECT/
PROGRESSIVE
Setting the video channel / Setting the language
To view playback of a recorded tape
or DVD disc, or to watch a program
selected by the VCR's channel
selector, the TV must be set to
channel 3 or 4 (video channel).
NOTES:
• When shipped from factory, the
video channel is set to CH 3.
• If the unit does not operate
properly, or No key operation (by
the unit and/or the remote control):
Static electricity, etc., may affect the
player's operation. Disconnect the AC
power cord, then connect it again.
• Both the VCR and the DVD have their
own menu option (See page 34).
• If no buttons are pressed for more
than 60 seconds, the MENU screen
will return to normal TV-operation
automatically.
You can choose from three different languages (English,
French and Spanish) for the on-screen displays.
When a TV is connected with the 75 ohm coaxial cable only.
1
Press and hold 3 or 4 on the remote
control for 3 seconds in the standby
mode to select CH 3 or 4. The selected
channel number will flash on the display for about 4 seconds.
2
Turn ON the TV and set to CH 3 or 4 to correspond with the
channel selected in step 1.
5
Press TV/VCR to select the VCR position.
The VCR indicator will appear in the display.
6
Select any channel to receive a TV station in your area.
The channel number will appear on the screen for about
4 seconds.
For a push-button TV tuner
If CH 3 or 4 corresponding to the video channel cannot be tuned
on your TV, proceed as follows: set the VCR 3/4 channel selector
and the TV to CH 3 or 4, play back a prerecorded tape and tune
the TV to receive a sharp color picture from the video cassette
recorder. Refer to your TV owner's manual for details.
Setting the video channel
Setting the language
3 Press SET + or – to select the
desired language: English (EN-
GLISH), Spanish (ESPAÑOL) or
French (FRANCAIS), then press
ENTER.
1
2
Press SET + or – to select the
“LANGUAGE” option, then press
ENTER.
4
Press VCR MENU until the MENU screen is cleared.
〈+/-/ENTER/MENU〉
MENU
TIMER REC SET
AUTO REPEAT ON OFF
ON OFF SAP
CH SETUP
SYSTEM SETUP
á+/-/ENTER/MENUñ
SYSTEM SETUP
CLOCK SET
LANGUAGE/IDIOMA/LANGUE
NO NOISE BACKGROUND
ON OFF
3
Press POWER to turn on the DVD/VCR.
4
Press VCR/DVD to select the VCR mode. The VCR indicator
on the front panel will light.
Press VCR MENU.
The VCR menu screen will appear. Press SET + or – to select
the “SYSTEM SETUP” menu, then
press ENTER.
If you use the unit for the first time
and press VCR MENU, instead of
the main menu screen on the right
the “SYSTEM SETUP” menu
screen in step 2 may appear.
