Motorola WR850GP User Manual

Page 64

Configuration

Section 3

WR850

3-31

Blocking Internet Use at All Times – Using IP Addresses

For this example, we assume that:

•

there is one PC to be restricted, and

•

the IP address assigned to that PC is 192.168.10.4.

Step 1: At LAN Usage Filters, under LAN IP Address Range, on consecutive lines enter

the IP address(es) of the PC(s) to be restricted.

NOTE: If you intend to restrict multiple clients in the home, it is best to assign them consecutive

IP addresses, to allow you to enter a single LAN IP Address Range without disabling
another client.

Step 2: Under Protocol, select TCP on one line and UDP on the next.

Step 3: Under Destination Port Range, enter the entire port range (0 through 65535)

on both lines.

Step 4: At the end of each line, check the Enabled box to engage the filters.

Step 5: At the bottom of the page, click the Apply action button.
