Appendix A
A-1: Default Settings
TIP: Press the Default (SF-Reset, or Soft-Reset) switch on the housing of a powered-on advanced AP to
reset the configuration settings to factory-default values.
Setting Name Default Value
Global
User Name root
Password root
Host Name “M95-10xxxxxx” where xxxxxx = last 6 hex digits
of the AP's MAC address
IEEE 802.11b
Regulatory Domain Spain
Channel Number 11
SSID wireless
SSID Broadcasts Enabled
Transmission Rate 11Mbps
Transmission Power High
MAC Address See the label on the housing of the advanced AP.
Security Mode 128-bit WEP
Selected WEP Key Key #1
WEP Key #1 Generated by using Host Name as the passphrase
WEP Key #2 00-00-00-00-00-00-00-00-00-00-00-00-00
WEP Key #3 00-00-00-00-00-00-00-00-00-00-00-00-00
WEP Key #4 00-00-00-00-00-00-00-00-00-00-00-00-00
MAC-Address-Based Access
Control
Disabled
Access Control Table Type Inclusive
LAN Interface
Method of obtaining an IP
Address Obtain automatically by DHCP.
If the AP fails to obtain an IP address from a
DHCP server after 75 seconds, it assigns
192.168.0.1 as its IP address.
IP Address 192.168.0.1
Subnet Mask 255.255.255.0
Default Gateway 0.0.0.0
Management
SNMP Enabled
SNMP read community public
SNMP write community private
UPnP Disabled
A-2: LED Definitions
There are several LED indicators on the housing of an advanced AP. They are defined as follows:
ALV: Alive. Blinks when the advanced AP is working normally.
RF: Activity on the IEEE 802.11b interface.
LAN: Activity on the Ethernet LAN interface.
PWR: Power is applied.
