Roller parts, Parts list, Additional roller covers – Graco Inc. 245907 User Manual
Page 7
309511
7
Roller Parts
ti2135b
1
4
3
2
7
5
6, 9
Parts List
Ref.
No.
Part No.
Description
Qty.
1
FRAME, roller
1
2
245999
CAP, end (includes seal and retainer)
1
3
246277
CAP, end (includes seal and retainer)
1
4
15B065
DIFFUSER
2
o–ring)
1
5
197106
CLIP, roller
1
6
115524
GASKET
1
7
186678
ROLLER, cover, 9 inch,
1/2 in. (13 mm) nap
1
9
197118
SWIVEL, fitting
1
Additional Roller Covers
For the best coverage it is important to choose the
right roller cover nap for the surface you are rolling.
For rougher surfaces choose a thicker nap. Use a
thinner nap on smooth surfaces.
Part No.
Nap Size
Surface Texture/
Example
Material
243063
9 in. (23 cm);
1/2 in. (13 mm)
Smooth/ metal,
wood, trim, drywall
medium
243064
9 in. (23 cm);
3/4 in. (19 mm)
Rough/
cement, brick
heavy
243065
9 in. (23 cm);
1-1/4 in. (32
mm)
Extra–rough/
cement block, tex-
tured walls, ceil-
ings
heavy
