Generac Power Systems 009600-5 User Manual
Page 47
Generac
®
Power Systems, Inc. 45
ITEM PART NO. QTY.
DESCRIPTION
1
86318
1
BASE, MOUNTING
2
90141
1
GROUND CABLE
3
46911
4
MOUNT, (RUBBER)
4
25017
8
SCREW HHC 3/8-16 X 1/2 G5
5
46526
2
WASHER LOCK M10
6
22129
8
WASHER LOCK M8-5/16
7
72391
2
SKID, RUBBER MOUNT
8
77603
2
SAFETY BOLT 5/16"-18 x 3-1/2"
9
22259
2
NUT HEX 5/16-18 STEEL
10
52858
6
NUT LOCK M8
11
51730
2
SCREW HHC M8-1.25 X 60 G8.8
12
29459
2
SPRING, BELT TENSION
13
75215
2
WASHER, SPRING CNTR
14
73146
4
SLIDE (NYLON)
15
75209
2
SUPPORT, NYLON SLIDE
16
73174
1
MANIFOLD, EXHAUST
17
79678
2
RING, SEALING
18
40976
4
SCREW SHC M8-1.25 X 20 G12.9
19
72383
2
GASKET, COLLECTOR PAN
20
90859
1
COVER PLATE -EXTERNAL
21
75224-B
1
PULLEY, ENGINE
22
73106-B
1
PULLEY, ALT.
23
75216
1
BELT (POLY V 4L)-40"
24
49451
1
WASHER FLAT SPECIAL .406 I.D.
25
42633
1
SCREW HHC 3/8-24 X 1 G5
26
77017
1
GUIDE, BLOWER HOUSING
27
73118
1
SCREW HHC 3/8-24X2-1/4 G8
28
74906
5
SCREW TAPTITE M6X20 BP
30
72375
1
HOUSING, BLOWER
31
73185
1
SPACER ROLL 2.36X.230X.042 BRZ
32
22097
7
WASHER LOCK M6-1/4
33
77682
1
SCREW HHC M5-0.8 X 80 G8.8
34
75242
4
SPRING, GENERATOR SET MT
35
49813
2
NUT HEX M6 -1.0 G8 YEL CHR
36
45757
2
SCREW HHC M6-1.0 X 25 G8.8
37
A5802
1
TINNERMAN CLIP
38
22413
1
SCREW HHC 1/4-20 X 1 G5
39
22145
2
WASHER FLAT 5/16 ZINC
40
22237
8
WASHER LOCK 3/8
41
A8475
1
WASHER SPECIAL LOCK M5
42
26925
1
PLUG STD PIPE 3/8 STEEL SQ HD
43
75710-A
1
TUBE, OIL FILL AND DRAIN
44
74958
1
CAP & DIPSTICK ASSEMBLY
45
67871
1
O-RING, CAP
46
A5508
1
OIL FILL TUBE GASKET
ITEM PART NO. QTY.
DESCRIPTION
47
75711
1
PIPE, OIL DRAIN ADAPTOR
48
92120
2
NUT LOCK TRIC M6 X 1.0 Y/ZNC
49
D1227
1
STARTER CONTACTOR
50
D1741
2
BOOT, STARTER CONTACTOR
51
24114
2
NUT HEX 5/16-24 STEEL
52
D1741A
1
BOOT, BATTERY CABLE
53
22152
2
WASHER LOCK #10
54
22158
2
NUT HEX #10-32 STEEL
55
133-74260
1
CABLE, STARTER
56
73179
1
OIL FILTER SUPPORT
57
70185
1
FILTER, OIL (FRAM#PH3614)
58
A8584
1
10 PSI-SWITCH, OIL PRESSURE
59
74948
3
FITTING COMP 5/16X1/8 SLF-ALGN
60
74950
1
TUBE, OUTER OIL
61
74951
1
TUBE, INNER OIL
62
73134
1
ADAPTOR, OIL FILTER ADAPTER
63
38750
3
SCREW HHC M6-1.0 X 30 G8.8
64
74949
1
ELBOW 90D TUBE CMP 5/16X1/8NPT
65
68548
1
GASKET, OIL FILTER ADAPTER
66
C4006
1
CABLE,BATTERY
67
29289
--
TAPE ELEC NON-UL FOAM 1/16X1/2
68
22131
1
WASHER FLAT 3/8 ZINC
69
75281
1
SWITCH, HIGH TEMPERATURE
70
C1085
2
SCREW PPHM M3-0.5 X 8
71
43182
2
WASHER LOCK M3
72
45756
9
SCREW TAPTITE M6X10 YEL CHR
73
75237
4
WASHER, SPRING RETAINER
74
D1624
1
BOOT, OIL PRESSURE SWITCH
75
75474
1
BOOT, TEMPERATURE SWITCH
76
90800
1
ELBOW, EXHAUST
77
94670
1
EXHAUST CLAMP
78
75226
1
COVER, AIR
79
56893
23
SCREW CRIMPTITE #10-24 X 1/2
80
75229
1
SLIDE PAN, GASKET
81
D3158
1
SLIDE PAN
82
79246
6
CAPSCREW, HEX HEAD- M6-1.00 x
16mm WITH LOCK WASHER
83
22473
7
WASHER FLAT 1/4 ZINC
84
67210
1
DECAL-GROUND
85
72384-C
1
COVER, EXHAUST OUTLET
86
23897
6
WASHER FLAT #10 ZINC
87
77643
1
GASKET, EXHAUST OUTLET
88
81105
2
FLANGE NUT, (SPECIAL) 5/16"-18
89
90088
1
CLAMP VINYL .25 X .28 Z
90
A1658
2
LOCKWASHER, SPECIAL ¼"
Section 10 — Exploded Views and Parts Lists
PRIMEPACT 66G and 66LP Recreational Vehicle Generators
Base and Pulleys – Drawing No. 0D3154-A
