Generac Power Systems 009600-5 User Manual
Page 45
Generac
®
Power Systems, Inc. 43
ITEM PART NO. QTY.
DESCRIPTION
1
086318
1
BASE, MOUNTING
2
090141
1
GROUND CABLE
3
046911
4
MOUNT VIBR 1.50X1.38 X 3/8-16)
4
025017
8
SCREW HHC 3/8-16 X 1/2 G5
5
046526
2
WASHER LOCK M10
6
022129
8
WASHER LOCK M8-5/16
7
072391
2
SKID, RUBBER MOUNT
8
077603
2
SAFETY BOLT 5/16-18 x 3 1/2"
9
022259
2
NUT HEX 5/16-18 STEEL
10
052858
6
NUT LOCK M8
11
051730
2
SCREW HHC M8-1.25 X 60 G8.8
12
029459
2
SPRING, BELT TENSION
13
075215
2
WASHER, SPRING CNTR
14
073146
4
SLIDE (NYLON)
15
075209
2
SUPPORT, NYLON SLIDE
16
073174
1
MANIFOLD, EXHAUST
17
079678
2
RING, SEALING
18
040976
4
SCREW SHC M8-1.25 X 20 G12.9
19
072383
2
GASKET, COLLECTOR PAN
20
090859
1
COVER PLATE -EXTERNAL
21
075224B
1
PULLEY, ENGINE
22
073106B
1
PULLEY, ALTERNATOR
23
075216
1
BELT (POLY V 4L)-40"
24
049451
1
WASHER FLAT SPECIAL .406 I.D.
25
042633
1
SCREW HHC 3/8-24 X 1 G5
26
077017
1
GUIDE, BLOWER HOUSING
27
073118
1
SCREW HHC 3/8-24 X2-1/4 G8
28
074906
7
SCREW TAPTITE M6 X 20 BP
29
091123
1
BRACKET-FUEL PUMP
30
072375
1
HOUSING, BLOWER
31
073185
1
SPACER ROLL 2.36 X.230 X.042 BRZ
32
022097
7
WASHER LOCK M6-1/4
33
077682
1
SCREW HHC M5-0.8 X 80 G8.8
34
075242
4
SPRING, GENERATOR SET MT
35
049813
2
NUT HEX M6 -1.0 G8 YEL CHR
36
045757
2
SCREW HHC M6-1.0 X 25 G8.8
37
090475
1
FUEL PUMP
38
087769
1
FUEL FILTER
39
087768
1
FITTING COMP 1/4X1/8 SLF-ALGN
40
087770
1
FUEL LINE
41
0A8475
1
SPECIAL LOCK WASHER, M5
42
026925
1
PLUG STD PIPE 3/8 STEEL SQ HD
43
075710A
1
TUBE, OIL FILL AND DRAIN
44
074958
1
CAP & DIPSTICK ASSEMBLY
45
067871
1
O-RING, CAP
46
0A5508
1
OIL FILL TUBE GASKET
47
075711
1
PIPE, OIL DRAIN ADAPTOR
49
022413
1
SCREW HHC 1/4-20 X 1 G5
ITEM
PART NO.
QTY.
DESCRIPTION
50
0A5802
1
TINNERMAN CLIP
51
022237
8
WASHER LOCK 3/8
52
022145
2
WASHER FLAT 5/16 ZINC
54
092120
2
NUT LOCK TRIC M6 X 1.0 Y/ZNC
55
0742600133
1
CABLE, STARTER
56
073179
1
OIL FILTER SUPPORT
57
070185
1
FILTER, OIL (FRAM#PH3614)
58
0A8584
1
10 PSI-SWITCH, OIL PRESSURE
59
074948
3
FITTING COMP 5/16 X1/8 SLF-ALGN
60
074950
1
TUBE, OUTER OIL
61
074951
1
TUBE, INNER OIL
62
073134
1
ADAPTOR, OIL FILTER ADAPTER
63
038750
3
SCREW HHC M6-1.0 X 30 G8.8
64
074949
1
ELBOW 90D TUBE CMP 5/16 X
1/8NPT
65
068548
1
GASKET, OIL FILTER ADAPTER
66
0C4006
1
CABLE, 30" LONG
67
029289
-
TAPE ELEC NON-UL FOAM 1/16X1/2
68
022158
2
NUT HEX #10-32 STEEL
69
075281
1
SWITCH, HIGH TEMPERATURE
70
0C1085
2
SCREW PPHM M3-0.5 X 8
71
043182
2
WASHER LOCK M3
72
022152
2
WASHER LOCK #10
73
075237
4
WASHER, SPRING RETAINER
74
0D1624
1
BOOT, OIL PRESSURE SWITCH
75
075474
1
BOOT, TEMPERATURE SWITCH
76
090800
1
ELBOW, EXHAUST
77
094670
1
CLAMP, EXHAUST
78
075226
1
COVER, AIR
79
056893
23
SCREW CRIMPTITE #10-24 X 1/2
80
075229
1
SLIDE PAN, GASKET
81
0D3158
1
SLIDE PAN
82
079246
6
CAPSCREW, HEX HEAD- M6-1.00 x
16mm WITH LOCK WASHER
83
022473
5
WASHER FLAT 1/4 ZINC
84
0D1741A
1
BOOT, BATTERY CABLE
85
072384C
1
COVER, EXHAUST OUTLET
86
024114
2
NUT HEX 5/16-24 STEEL
87
077643
1
GASKET, EXHAUST OUTLET
88
0D1741
2
BOOT, BATTERY CABLE
89
0D1227
1
CONTACTOR, STARTER
90
0A1658
3
LOCKWASHER, SPECIAL ¼"
91
090088
1
CLAMP VINYL .25 X .28 Z
92
022131
1
WASHER FLAT 3/8 ZINC
93
081105
2
FLANGE NUT, (SPECIAL) 5/16"-18
94
023897
6
WASHER FLAT #10 ZINC
95
067210
1
DECAL-GROUND
96
045756
9
SCREW TAPTITE M6X10 YEL CHR
Section 10 — Exploded Views and Parts Lists
PRIMEPACT 66G and 66LP Recreational Vehicle Generators
Base and Pulleys – Drawing No. 0D3151-A
