COMMUNICATION PROGRAMMING GUIDE
Field # Low Speed Contact ID High Speed Express
*46, *48 Choose transmission No effect No effect No effect
speed and frequency
*52, *53 Send as either 4+2 No effect No effect No effect
or expanded
*79, *80 Enables alarm restores Enables alarm restores Enables alarm restores Enables alarm restores
*49 Add checksum digit No effect Add checksum digit No effect
*81, *82 Define codes and 1st digit enables report 1st digit enables report Define codes and
selects 4+1 or 4+2 if it is non-zero if it is non-zero selects 4+1 or 4+2
*54, *56, *59, *61, Defines alarm event Enables reports Assigns reporting channel Defines alarm event
*64, *66, *69, *71, code for all reports from this zone. code
*74, *76 Enables alarm reporting.
*55, *57, *60 Defines code and No effect No effect Defines code and
*62, *65, *67, selects 4+1 or 4+2 selects 4+1 or 4+2
*70, *72, *75, *77
*58, *63, *68,
Enables report and Enables report Enables report Enables report and selects
*73, *78 selects code. Note: Note: Alarm channel 1st digit of. the 2-digit
event
No restores if must be programmed. code. NOTE: No restores
event not sent. (01-15) if event not sent.
*50 Sescoa/Radionics; No effect No effect No effect
Selects fixed digit time
instead of fixed interdigit.
NOTES Note: Low Speed will
not send 3+2 messages.
Zone ID digit is suppressed.
Summary Of Default Consequences
Loading communication defaults results in the following:
Low Speed
( * 9 4 * 8 0 )
¥ Selects low speed, standard format with no checksum, for both phone numbers.
¥ Assigns the following report codes:
03 for zones 2-47
01 for zones 1 & 48-55 (fire zones)
02 for zones 62,63 (panic transmitter), & 95, 96, 99 (keypad panics)
09 for all alarm restores
¥ Enables all zone type alarm restores.
¥ Disables reporting Troubles, Trouble Restores, Bypass, Bypass Restores for all zones.
A D E M C O
Express
(*94*81)
¥ Selects Ademco express reporting format, with checksum, for both phone numbers.
¥ Report codes for zones 1-64, RF receivers and keypad panics are sent as their
respective zone ID numbers (01-64, 87-91, 95-99), Duress is sent as "DD". Alarm
restore is "E" + 2nd digit.
¥ Enables all zone type alarm restores.
¥ Disables reporting Troubles, Trouble Restores, Bypass, Bypass Restores for all zones.
ADEMCO High
Speed (*94*82)
¥ Selects Ademco High Speed format, with no checksum, for both phone numbers.
¥
Reporting is assigned to the following channels:
Channel 1 for zones 1 & 48-55 (Fire zones)
Channel 2 for zones 2-8
Channel 3 for zones 9-16
Channel 4 for zones 17-31
Channel 5 for zones 32-47 (RF interior zones)
Channel 6 for zones 56-61
Channel 9 for zones 62 & 63 (panic transmitter)
Channel 7 for zone 87 and for 2nd receiver (88 & 89) & polling loop short (97)
Channel 8 for first receiver (90 & 91)
Channels 10, 11 & 12 for keypad panics 95, 96 & 99 respectively
¥ Enables all zone type alarm restores.
¥ Enables Duress to be sent.
¥ Disables reporting Troubles, Trouble Restores, Bypass, Bypass Restores for all zones.
A D E M C O ' s
Contact ID
( * 9 4 * 8 3 )
¥ Selects Contact ID format for both phone numbers.
¥ Reporting is enabled for all zones.
¥ Enables all zone type alarm restores.
¥ Refer to the SYSTEM COMMUNICATION section for event code definitions.
