Contact ID Reporting This is the only format that can identify all 64 protection zones by their unique
zone (Contact) ID numbers, and provides a 1-digit event qualifier and 3-digit,
specifically defined event code which quickly identifies the condition being
reported.
Contact ID reports in DTMF (Dual Tone Multi-Frequency @ 10 characters per
second) and responds to a 1400 Hz followed by 2300 Hz handshake, and a 1400
Hz kissoff. This format also uses checksum instead of two message verification. A
complete report takes under 3 seconds.
Contact ID Reporting takes the format: CCCC Q EEE GG ZZZ
where:
CCCC = Customer (subscriber) number.
Q
= Event qualifier, where: E=new event (1) and R= restore (3)
EEE = Event code (3 hexadecimal digits), defined in the table below.
GG = Partition number.
ZZZ = Zone/contact ID number reporting the alarm (001-099), or user
number (001-099) for open/close reports. System status messages
(AC Loss, Walk Test, etc.) contain zeroes in the ZZZ location.
TABLE OF CONTACT ID EVENT CODES
C o d e Definition
110 Fire Alarm
121 Duress
122 Silent Panic
123 Audible Panic
131 Perimeter Burglary
132 Interior Burglary
133 24 Hour Burglary (zone type 11 if supported)
134 Entry/Exit Burglary
135 Day/Night Burglary
150 24 Hour Auxiliary
301 AC Loss
302 Low System Battery
305 System Reset
306 Program Tamper
309 Battery Test Fail
332 Poll Loop Short-Trouble
333 Addressable Device Failure
373 Fire Loop Trouble
380 Trouble (global)
C o d e Definition
381 Loss of Supervision - RF
382 Loss of RPM Supervision
383 RPM Sensor Tamper
384 RF Transmitter Low Battery
401 O/C By User
403 Power-Up Armed
406 Cancel by User
407 Remote Arm/Disarm (Download)
408 Quick Arm
409 Keyswitch O/C
411 Call back Requested
441 Armed STAY
570 Bypass
602 Periodic Test
606 Audio Alarm Verification to follow (AAVÐlisten-in)
607 Walk Test Mode, 2-Way Audio Test
621 Event Log Reset
625 Time/Date Reset
626 Time/date inaccurate
A D V I S O R Y :
Ademco's new Contact ID reporting is capable of uniquely reporting all 64 zones of information, as well as
openings and closings for all 70 users, to central stations equipped with the Ademco 685 receiver using software
level 4.4 or higher. Must be level 4.6 to fully support all new VISTA-40 report codes. 685 software levels below 4.4
cannot support Contact ID reporting. For information regarding updating the 685 receiver, contact the Technical
Support group (see C
ONTACTING TECHNICAL SUPPORT s ection toward the end of this manual).
N O T E : Contact ID event code Т606У is sent only if a VIM, and at least one 2-way voice keypad is used, and the
AUTO CALLBACK option is disabled. If AUTO CALLBACK option is enabled, then the restriction that
the 685 Rev number must be 4.6 or higher no longer applies, and the 2-way voice feature will work with
ANY central station receiver.
