Power-Up Procedure 1. Fill out the Polling Loop Current Draw and Auxiliary Device Current Draw
Worksheets shown below. Make sure that the currents drawn from these
outputs do not exceed their respective ratings.
CAUTION: Failure to observe the polling loop current rating will cause a
polling loop malfunction. Failure to observe the auxiliary output current rating
will result in a battery which does not charge properly, or possibly a tripped
circuit breaker.
2. Wire the 1361 transformer (1361CN in Canada) to terminals 1 & 2 on the
control panel (before connecting the battery), as shown in the SUMMARY OF
CONNECTIONS diagram. Do not plug in at this time.
3. Connect all polling loop and auxiliary devices, such as keypads, PIRs, etc.
4. Plug the transformer into a 24-hour, uninterrupted AC outlet. After a few
seconds, the green READY LED on the keypad(s) should light and the
keypad(s) should display DISARMED READY TO ARM (Alpha keypads), or
READY (Fixed-word keypads).
5. Connect the battery to the battery tabs on the control board using the battery
cables supplied (use Red for + to +, Black for Ð to Ð). See the SUMMARY OF
CONNECTIONS diagram.
POLLING LOOP CURRENT DRAW WORKSHEET
RPM DEVICE C U R R E N T # UNITS TOTAL CURRENT
998MX PIR 1mA
4191SN Contact 1mA
4194 Contact 1 mA
4192SD Photo Smoke 0.4 mA
4192SDT Smoke w/Heat 0.4 mA
4192CP Ionization Detector 0.4 mA
4275 Dual Element PIR 1 mA
4278 Quad Element PIR 1 mA
4190WH 2-Zone RPM 1 mA (LOW)
2 mA (HIGH)
4208 8-Zone RPM 16 mA
4278EX-SN PIR 1mA
4939SN Contact 1mA
4959SN Contact 1mA
TOTAL CURRENT *
* If the total current draw exceeds 64 mA, a 4197 Loop Extender module must be used.
AUXILIARY DEVICE CURRENT DRAW WORKSHEET
D E V I C E C U R R E N T # UNITS TOTAL CURRENT
6128 Keypad 30mA
6137 Keypad 85mA
6139 Keypad 100mA
6139AV Keypad 200mA
675 Ground Start Module 50 mA
Built-in Polling Loop (total poll loop worksht)
4281 RF Receiver 35mA
5881 RF Receiver 60mA
4197 Poll Loop Extender 80 mA
4204 Relay Module 15mA standby
40mA
per active relay
VIM Voice Interface Module. 80mA
*
*
TOTAL CURRENT (750mA max)
* If using hard-wire devices such as PIRs, refer to the specifications for that particular unit's current draw.
Only applies if powered from Control's auxiliary power.
