Identification – Grizzly G9744Z User Manual
Page 8
-6-
G9744Z Metal Cutting Bandsaw
Figure 1. G9744Z machine identification.
Identification
A
C
B
D
E
H
I
J
K
M
A. Blade Tension Handwheel
B. Lift Handle
C. Vise Handwheel
D. Coolant Drip Pan
E. Work Stop
F. Pulley Cover
G. Control Panel
H. Blade Guide Scale
I. Blade Guide Knob
J. Coolant Valve Control
K. Bow
L. Blade Guides
M. Wheel Covers
N. Chip Tray
F
M
N
G
L
