Page 40
-38-
G9744Z Metal Cutting Bandsaw
Electrical Components
Figure 47. Limit switch (SQ1).
Figure 50. Pump motor wiring and
capacitor (M2).
Figure 49. Control panel wiring.
Figure 48. Junction box (M1).
SB4
SB1
SB3
L
Figure 51. G9744Z Contactor & relay electrical box.
Fuse (FU 2A)
(KM1)
Contactor
(TC)
Transformer
(KM1)
Relay
(KM2) Relay
