Grizzly 12" Cold Cut Saw G0682 - Manual (Page 45)

g0682 12" Cold Cut saw (mfg. since 12/10)
-43-
Control box
1 2
3 4
3
L2
5
L3
13
NO
2
T1
4
T2
6
T3
14
NO
97 NO 98 NO
95 NC 96 NC
2
T1
4
T2
6
T3
1
L1
TC
11
TRANSFORMER
POWER
INDICATOR
HIGH/LOW
SPEED
SWITCH
ON/OFF
SWITCH
TRIGGER
SWITCH
NO NC
COM
S
6
4 R
3 2 5
T
1
RESET
OVERLOAD
RELAY
TEND THR12
6.5
A RC
8
5
15A 15A 15A 15A
0V 0V 240V 24V
CONTACTOR
TEND 220V
102-1
102
102-2
102-3
102-4
102-5
102-6
102-7
102-8
102-10
102-9 102-14
102-11
102-12
102-13
REF PART # DESCRIPTION REF PART # DESCRIPTION
102 P0682102 CONTROL BOX 102-8 P0682102-8 TWO STEP SWITCH
102-1 P0682102-1 CASE 102-9 P0682102-9 FUSE 15A
102-2 P0682102-2 CONTACTOR TECD TC-11 220V 102-10 P0682102-10 FUSE HOLDER
102-3 P0682102-3 TRANSFORMER 250V 102-11 P0682102-11 OL RELAY TEND 5-8A
102-4 P0682102-4 BACKING PLATE 102-12 P0682102-12 JUNCTION BLOCK
102-5 P0682102-5 INDICATOR LIGHT 102-13 P0682102-13 TRIGGER SWITCH
102-6 P0682102-6 ON/OFF SWITCH 102-14 P0682102-14 FUSE 1A
102-7 P0682102-7 COVER
