-24-
g0682 12" Cold Cut saw (mfg. since 12/10)
Cutting fluid
filling Cutting fluid Reservoir
1. disCoNNeCt saW From poWer!
2. remove the cap screws and washers from
the cutting fluid reservoir ( figure 34).
Draining/Cleaning Cutting fluid
Reservoir
1. disCoNNeCt saW From poWer!
2. Wearing protective equipment, drain and dis-
pose the cutting fluid following government-
approved disposal regulations for your area.
3. use a rag to wipe out residual fluid and
sludge.
4. Clean the cutting fluid screens in the machine
base and the tank ( figure 35).
Used cutting fluid is a
poison hazard. Use per-
sonal protection when
handling this material.
failure to do so may
result in illness or death.
3. slide the tray out from the machine base.
4. Wearing protective equipment, fill the reser-
voir with 2¼ quarts of a suitable, water-based
cutting fluid. refer to the manufacturer's
specifications for the proper water/oil mix.
5. slide the tray back into the base and replace
the cap screws and washers.
figure 34. opening cutting fluid reservoir.
Cap screws
Cutting Fluid reservoir
figure 35. Cutting fluid screens.
Cutting Fluid screens
Tip: Place a magnet in the cutting fluid reservoir
under the drain screen to collect metal chips and
prevent them from being drawn into the pump.
Periodically remove and clean the magnet.
