90° door swing, Design guide – GE Monogram ZICS360 LH User Manual
Page 5
1/4"
1/2"
3/4"
1"
1-1/4"
1/4"
1/2"
3/4"
1"
1-1/4"
1-1/2"
23-7/8"
From Rear of
Refrigerator
3/4" Overlay
Panel
(Nominal Size)
Case Trim
Refrigerator
Door
5
Top View
90° DOOR SWING
(optional setting)
Scale 1:1
Frameless Cabinets: The
case trim overlaps cabinets
at the top and sides.
Therefore, frameless
cabinets may require filler
strips to prevent interference
with cabinet door swing. The
opening must allow for filler
strips.
Design Guide
