Page 41
-39-
REF PART # DESCRIPTION
101 X1702101
HANDLE
102 X1702102
HANDWHEEL
103 XPB09
HEX BOLT
5
⁄
16
"-18 x
1
⁄
2
"
104 XPSS15
SETSCREW
3
⁄
8
"-16 x
3
⁄
8
"
105 XPSS08
SETSCREW
5
⁄
16
"-18 x
1
⁄
2
"
106 X1702106
COLLAR
107 XPSB07
CAP SCREW
5
⁄
16
"-18 x
3
⁄
4
"
108 X1702108
SHAFT MOUNT
109 X1702109
BUSHING
111 X1702111
WORM SHAFT
113 XP51103
BEARING
114 X1702114
GIB
115 X1702115
ELEVATION HOUSING
116 XPN02
HEX NUT
5
⁄
16
"-18
118 XPB72
HEX BOLT
1
⁄
2
"-13 x 2"
119 XPLW07
LOCK WASHER
1
⁄
2
"
120 XPLN07
LOCK NUT
5
⁄
8
"-11
121 X1702121
GEAR 25T
122 XPK06M
KEY 5 x 5 x 10mm
127 XPW07
FLAT WASHER
5
⁄
16
"
128 X1702128
HAND KNOB
3
⁄
8
"-16
129 XPB25
HEX BOLT
3
⁄
8
"-16 x 1
3
⁄
4
"
131 XPB19
HEX BOLT
1
⁄
4
"-20 x
1
⁄
2
"
132 XPW06
FLAT WASHER
1
⁄
4
"
133 X1702133
“L” BRACKET
134 W1702134 POINTER
135 XPW07
FLAT WASHER
5
⁄
16
"
136 X1702036
ELEVATION LEAD SCREW
137 X1702137
CARTRIDGE SLIDE
138 XPB15
HEX BOLT
5
⁄
16
"-18 x
3
⁄
8
"
139 X1702146
V-BELT 7m690
141 XPB22
HEX BOLT
5
⁄
16
"-18 x 1
3
⁄
4
"
142 XPW07
FLAT WASHER
5
⁄
16
"
143 XPLW01
LOCK WASHER
5
⁄
16
"
144 XPK06M
KEY 5 x 5 x 10
145 X1702145-2 CAPACITOR COVER
147 X1702147
MOTOR PULLEY
148 XPW01
FLAT WASHER
1
⁄
2
"
149 XPLW07
LOCK WASHER
1
⁄
2
"
150 XPSS02
SETSCREW
5
⁄
16
"-18 x
3
⁄
8
"
151 X1702151
MOTOR MOUNT PLATE
152 X1702152
MOTOR 3 HP
153 X1702145-3 WIRE BOX COVER
154 X1702145-4 MOTOR FAN
155 X1702145-5 MOTOR FAN COVER
156 XPSS20
SETSCREW
5
⁄
16
"-18 x 1
1
⁄
2
"
157 XPB55
HEX BOLT
1
⁄
2
" - 13 x 1
1
⁄
2
"
158 X1702137
CABLE CLAMPS
159 X1702152-1 START CAPACITOR
161 XPW01
FLAT WASHER
1
⁄
2
"
REF PART # DESCRIPTION
PARTS
