Grizzly G9003 - Manual (Page 15)

-15 - G9004 Portable Planer
001 P9003001 Pan Hd Screw M4 x 16
002 P9003002 Chip Cover
003 P9003003 Knob
004 P9003004 Scale Plate for Knob
005 P9003005 Flat Washer 10mm
006 P9003006 Main Frame
007 P9003007 Rivet
008 P9003008 Name Plate
009 P9003009 Cord Guard
010 P9003010 Cord
011 P9003011 Strain Relief
012 P9003012 Pan Hd Screw M4 x 18
013 P9003013 Noise Suppressor
014 P9003014 Switch
015 P9003015 Handle Cover
016 P9003016 Pan Hd Screw M4 x 25
017 P9003017 Bearing (6000LL8)
018 P9003018 Stop Ring E-9
019 P9003019 Fan
020 P9003020 Armature Assy (w/17&22)
021 P9003021 Insulation Washer
022 P9003022 Bearing (627LB)
023 P9003023 Field Assembly
024 P9003024 Pan Hd Screw M4 x 16
025 P9003025 Auxiliary Baffle Plate
026 P9003026 Pan Hd Screw M4 x 10
027 P9003027 Bearing Cover
028 P9003028 Carbon Brush
029 P9003029 Brush Holder Cap
030 P9003030 Indication Plate
031 P9003031 Screw M5 x 10
032 P9003032 Compression Spring
033 P9003033 Rubber Packing
034 P9003034 Front Base
035 P9003035 Pan Hd Screw M5 x 18
036 P9003036 Base
037 P9003037 Rubber Pin
038 P9003038 Bearing (608ZZ)
039 P9003039 Drum
040 P9003040 Rubber Pin
041 P9003041 Hex Hd Bolt M4 x 20
042 P9003042 Bracket
043 P9003043 Pan Hd Screw M4 x 20
044 P9003044 V-Pulley 4-20L
045 P9003045 Belt Cover
046 P9003046 Rubber Pin
047 P9003047 Pan Hd Screw M4 x 25
048 P9003048 Poly V-Belt 4-24L
049 P9003049 V-Pulley 4-37
050 P9003050 Bearing (6000ZZ)
051 P9003051 Ruber Pin
052 P9003052 Adjustment Plate
053 P9003053 Pan Hd Screw M4 x 5
054 P9003054 Drum Plate
055 P9003055 Hex Hd Flange Bolt M6 x 17
Ref. # Part # Description Ref. # Part # Description
