ES42 Series Edge Switches
Installation and User Guide (05/05)
3.5 Power Requirements, Power Supply Types for ES42 Series Switches
Magnum ES42 Series Switches are power-efficient and can work with an external AC
power supply. Magnum ES42 Series require a nominal 12VDC input version. The
extended temperature (H and P) versions are used for heavy duty industrial applications.
The 12V DC power input jack has a plug of 2.5mm,
center +ve , with 6 ft. cord. All the AC power supply
info detail is provided in Technical Specs Section 1.1.
The ES42 Series are designed to be used with UL
listed Class II power supplies.
ES42H or P with 12VDC/ 24VDC/ -48VDC
The ES42 Edge Switches provide reliable operation,
