ES42 Series Edge Switches Installation and User Guide (05/05)
Remove the Magnum ES42 Series Edge Switch from the shipping container. Be
sure to keep the shipping container should you need to ship the unit at a later date. In the
event there are items missing or damaged contact your supplier. If you need to return the
unit use the original shipping container. Refer to Section 5 Troubleshooting, for specific
return procedures.
2.2 Product Description
Magnum ES42 Series Switches are designed as an Ethernet edge solution in
heavy-duty industrial, military and un-controlled temperature applications, as well as an
economical solution for the growing requirements of managed networks. ES42, a six port
versatile family of compact Edge switches, loaded with factory configurable fiber options
and AC/DC power input options with Alarm terminal block and innovative packaging is
ready to serve the needs of edge-of-the network applications.
The Magnum ES42 family of Edge Switches have a wide breadth of port
configurability and fiber port type options - six 10/100 copper ports or four 10/100 copper
13
